- Page 1 External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 2: Safety Notices
FAR 2.101(a) or as "Restricted computer software" as defined in FAR 52.227-19 (June 1987) or any equivalent agency regulation or contract clause. Use, duplication or disclosure of Software is External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 3: Safety Summary
Do Not Modify the Do not install substitute parts or perform any unauthorized modification to the product. Instrument Return the product to an Keysight Sales and Service Office for service and repair to ensure that safety features are maintained. In Case of Damage Instruments that appear damaged or defective should be made inoperative and secured against unintended operation until they can be repaired by qualified service personnel. - Page 4 Both direct and alternating current Three phase alternating current Three phase alternating current Earth ground terminal Protective earth ground terminal Frame or chassis ground terminal Terminal is at earth potential External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
- Page 5 Caution, refer to accompanying documentation Caution, risk of electric shock Do not apply around or remove from HAZARDOUS LIVE conductors Application around and removal from HAZARDOUS LIVE conductors is permitted Caution, hot surface External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
- Page 6 Symbol Description Ionizing radiation CAT I IEC Measurement Category I CAT II Measurement Category II CAT III Measurement Category III CAT IV Measurement Category IV External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
- Page 7 Framework regulations under the terms of the Radio Communication Act of 1992. CE compliance marking to the EU Safety and EMC Directives. ISM GRP-1A classification according to the international EMC standard. ICES/NMB-001 compliance marking to the Canadian EMC standard. External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
- Page 8 External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 9: Table Of Contents
To power off the system Step 2. Remove the cover Step 3. Remove the front panel assembly Step 4. Remove the internal hard d isk drive Step 5. Install the SATA interface adapter External Boot Drive for Keysight Logic Analysis Systems Installation Guide... - Page 10 Step 7. Replace the cover Step 8. Connect and power up the external boot drive Step 9. Power up the logic analyzer Step 10. Recover the operating system and re-install software 3 Characteristics External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 11: Installation On 16900 Series Logic Analysis Systems
External Boot Drive for Keysight Logic Analysis Systems Installation Guide Installation on 16900 Series Logic Analysis Systems Step 1. Prepare the instrument for disassembly / 13 Step 2. Remove the cover / 15 Step 3. Remove the CPU tray / 16 Step 4. - Page 12 Begin with “Step 1. Prepare the instrument for disassembly" on page 13. Electrostatic discharge can damage electronic components. Use CAUTION grounded wrist straps and mats when handling electronic components. External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 13: Step 1. Prepare The Instrument For Disassembly
On the logic analysis system desktop click Start> Shut Down or if you are running remote desktop, click Start> Settings> Windows Security> Shut Down. This software power off does the following: • Closes all programs that are running. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... - Page 14 Unplugging power while the instrument is turned on or a power loss is similar to the long press of the power button with one exception: • When the system is plugged back in, it will power up and boot into Windows. External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 15: Step 2. Remove The Cover
Slide the cover back and up to remove. When reinstalling the handle assembly, ensure that the screws are torqued to 2.372 CAUTION Newton meters (21 inch pounds) so that they do not work themselves loose. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 16: Step 3. Remove The Cpu Tray
CPU motherboard, and this position should not shifted. Doing so can make it difficult to make a reliable connection between the PCI cards and the CPU motherboard. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... - Page 17 Use the tray levers to pry and disconnect the CPU board from the module interface board and slide the tray out being careful not to catch the loose cables on anything. External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 18: 16903A Cpu Tray
CPU motherboard, and this position should not shifted. Doing so can make it difficult to make a reliable connection between the PCI cards and the CPU motherboard. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... - Page 19 Installation on 16900 Series Logic Analysis Systems Slide the tray out being careful not to catch the loose cables on anything. External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 20: Step 4. Remove The Internal Hard Disk Drive
If you have a 16900A or 16902A frame, disconnect the power cable from the I/O board and remove it. (If you have a 16903A frame, the power cable was already disconnected from the module interface board.) External Boot Drive for Keysight Logic Analysis Systems Installation Guide... - Page 21 Using a Torx T15 screwdriver, remove the 4 screws that secure the hard drive to the hard drive plate. These screws are accessible through holes in the bottom of the CPU tray. External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 22: Step 5. Install The Sata Interface Adapter
SATA cable to an available SATA connector on the motherboard. If using the eSATA adapter card, press the card securely into the socket on the motherboard. Connect the eSATA cable to the external port on the interface card. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... - Page 23 Swing the plate back into place. Replace the screw(s). External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 24: Step 6. Replace The Cpu Tray
Step 8. Connect and power up the external boot drive If the eSATA cable is not already connected to the port on the SATA interface adapter in the 16900 series logic analysis system frame, do that now. Connect the other end of the eSATA cable to the external boot drive. -
Page 25: Step 9. Power Up The Logic Analysis System
In this case, continue with the steps in this and the next section. Locate the recovery DVD that shipped with your original logic analysis system. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 26: Step 10. Recover The Operating System And Re-Install Software
(http://www.keysight.com/find/la-sw-download) or with the application software CD. Install any additional application software. Restore the data and license files you backed up in “Step 1. Prepare the instrument for disassembly" on page 13. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 27: Installation On 16800 Series And 16901A Logic Analysis Systems
External Boot Drive for Keysight Logic Analysis Systems Installation Guide Installation on 16800 Series and 16901A Logic Analysis Systems Step 1. Prepare the instrument for disassembly / 29 Step 2. Remove the cover / 31 Step 3. Remove the front panel assembly / 32 Step 4. - Page 28 “Step 8. Connect and power up the external boot drive" on page 36. Electrostatic discharge can damage electronic components. Use CAUTION grounded wrist straps and mats when handling electronic components. External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 29: Step 1. Prepare The Instrument For Disassembly
On the logic analyzer desktop click Start> Shut Down or if you are running remote desktop, click Start> Settings> Windows Security> Shut Down. This software power off does the following: • Closes all programs that are running. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... - Page 30 Unplugging power while the instrument is turned on or a power loss is similar to the long press of the power button with one exception: • When the system is plugged back in, it will power up and boot into Windows. External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 31: Step 2. Remove The Cover
Slide the cover back to remove. When reinstalling the handle assembly, ensure that the screws are torqued to 2.372 CAUTION Newton meters (21 inch pounds) so that they do not work themselves loose. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 32: Step 3. Remove The Front Panel Assembly
• Front panel cable from the back-light inverter board. Using a Torx T10 screwdriver, remove 6 screws that secure the front panel to the chassis. Remove the front panel assembly. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 33: Step 4. Remove The Internal Hard Disk Drive
Remove the internal hard disk drive cables: a Disconnect the SATA cable from the motherboard and remove it. b Disconnect the power cable from the MIB board and remove it. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 34: Step 5. Install The Sata Interface Adapter
CPU tray between the motherboard and rear panel. If you are using the SATA-to-eSATA adapter plate, insert the adapter and connect the internal SATA cable to an available SATA connector on External Boot Drive for Keysight Logic Analysis Systems Installation Guide... - Page 35 Depending on the motherboard, the PCI slot location for the SATA NOTE interface card may be different. Replace the screw(s). External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
-
Page 36: Step 6. Replace The Front Panel Assembly
Connect the other end of the eSATA cable to the external boot drive. Turn the external boot drive power on by connecting its power cable and setting its power switch to the on position. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 37: Step 9. Power Up The Logic Analyzer
In this case, continue with the steps in this and the next section. Locate the recovery DVD that shipped with your original logic analysis system. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 38: Step 10. Recover The Operating System And Re-Install Software
(http://www.keysight.com/find/la-sw-download) or with the application software CD. Install any additional application software. Restore the data and license files you backed up in “Step 1. Prepare the instrument for disassembly" on page 29. External Boot Drive for Keysight Logic Analysis Systems Installation Guide... -
Page 39: Characteristics
External Boot Drive for Keysight Logic Analysis Systems Installation Guide Characteristics Operating Table 3 Operating Environment Environment Characteristics Shock: 80 g, 64 in/sec. Temperature: 5°C to 55°C (+41°F to 131°F). Humidity: 5% to 95% relative humidity, non-condensing. Altitude: -304.8 to 3,048 m (-1,000 to 10,000 ft). - Page 40 High-frequency: 20 to 300 Hz, 2.41 g rms. In non-operating conditions or in storage, do not expose the drive to CAUTION more than 5 to 500 Hz at 3.0 g rms. External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
- Page 41 External Boot Drive for Keysight Logic Analysis Systems Installation Guide...
- Page 42 This information is subject to change without notice. © Keysight Technologies 2005-2006, 2011-2014 Fifth Edition, November 2014 *E5862-97003* www.keysight.com...
