Machine description – quick overview
T drive 4 Rob 2
4.1.2
Rear view
Item
Symbol Description
1
analog
2
digital
3
4
16
0
12-pole connection socket
Control lead connection to the TIG module, connection socket
7-pole connection socket
Control lead connection to the TIG module, connection socket
Machine feet
Wire feed nipple (wire feed from external source)
Figure 4-2
099-000077-EW501
09.02.2011
