Technical Manual Switch Actuators AKI/AKS/AKK
4.3.2 Central function
The following illustration shows the setting options at the ETS‐Software:
Illustration 9: Central function
The following chart shows the dynamic range for this parameter:
ETS‐text
Central function
Chart 9: Central function
The central function can be switched on/off for every channel. For switching on this function, you
have to choose the option "active". By calling the central communication object, all channels with an
activated central function are switched on with their current parameterization. So switch‐on delays
or staircase functions are still kept.
The central function can make programming much more easier and your project can become more
clear.
The following chart shows the associated communication object:
Number Name
Central function
Chart 10: Communication object central function
4.3.3 Behavior at block/unblock
The following illustration shows the setting options at the ETS‐Software:
Illustration 10: Blocking function
The following chart shows the dynamic range for this parameter:
ETS‐text
Behavior when locked
Behavior when unlocked
Chart 11: Behavior at block/unblock
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
14
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[default value]

not active

active
Length Usage
1 Bit central switching of the channels
number depends to the number of channels
Dynamic range
[default value]

On

Off

no change
comment
switches the central function
on/off for this channel
comment
Behavior to a
blocking/unblocking process
