Premier Mounts PP-6 Assembly Instructions

PP-6, -6A

PP-6

NOTE:

The ceiling should be capable of supporting a weight of at least five times the projector or

monitor weight. If it cannot, the ceiling must be reinforced. Proper installation procedure by

qualified personnel as outlined in the installation instructions must be adhered to. Failure to do so

could result in serious personal injury.

Install the PP-6 securely to the ceiling structure in accordance with proper commercial standards. Use

suitable hardware depending on the installation requirements (Figure 1).

Install the desired length of 2" diameter NTP pipe with threaded ends for the PP-6.

Tighten the ¼" x 20 x 1/2" locking screw to the PP-6 to secure the pipe so it will not swivel.

Locking Screw

Installation Instructions

PP-6 and PP-6A Assembly Instructions

Figure 1

Page - 1 -
