- Page 1 ASSEMBLY INSTRUCTIONS MODEL RTA - 2333 Thanks for purchasing one of our products. Please read carefully the assembly instructions before the installation. Please save this manual for future reference. MODEL RTA-2333...
- Page 2 RTA-2333...
-
Page 3: Parts List
RTA-2333 PARTS LIST Right Panel Left Panel Back Panel Top Panel Support Tubes Bottom Panel Main Structure Short Tube Long Tube Front Tube Right Left X3 sets Back Tube Studs Slider... - Page 4 RTA-2333 Drawer Left Panel Drawer Front Panel Drawer Right Panel Drawer Bottom Panel Table Top Drawer Back Panel Handle Drawer Connect...
-
Page 5: Screws List
RTA-2333 SCREWS LIST PART QTY. ITEM PART QTY. ITEM 6X40 MM 6X25 MM 3X15 MM 6X60 MM Ф16 MM 4X35 MM 4X20 MM 4X14 MM 6X15 MM 6X35 MM... - Page 6 RTA-2333...
-
Page 7: Assembly Steps
RTA-2333 ASSEMBLY STEPS: Use screws F to assemble the Drawer Connects (21) to the Drawer Front Panel (14). Use screws B to assemble the Drawer Connects (21) to the Drawer Left and Right Panels (15 & 16). SCREWS SCREWS 3X15 MM... - Page 8 RTA-2333 Right Right Left Left REPEAT STEP 1 TO 5 FOR THE OTHER TWO DRAWERS Grab the 2 sets of the Drawer Sliders (13) and separate the flat SCREWS ones from the “L” shaped ones. Place the drawer upside- down as shown and use screws B to assemble the “L” shaped 3X15 MM Sliders to the Drawer Left &...
- Page 9 RTA-2333 SCREWS 6X40 MM First screw bolts A to the Left and Right Panel (1 & 2), then assemble 4PCS the Back Panel (3) as shown and as explained in page 5. First screw bolts A to the Top Panel (4) and Bottom Panel (5), then assemble these panels to the Left and Right Panel, Back Panel (1, 2 &...
- Page 10 RTA-2333 P.10 Use screws E to assemble the Support Tubes (6) to the Bottom Panel (5). SCREWS (UPSIDE-DOWN) 4X14 MM 16PCS SCREWS 6X15 MM Use screws F to assemble the Long Tube (9) to the Main Structure (7) and the Short Tube (8).
- Page 11 RTA-2333 P.11 Use screws F to assemble the Back Tube (11) to the Main SCREWS Structure (7) and the Short Tube (8). Please pay attention to the direction of the Front Tube (11). 6X15 MM 4PCS SCREWS 6X25 MM 2PCS Use screws H &...
- Page 12 RTA-2333 P.12 SCREWS 6X35 MM Use screws G & J to assemble the Front Tube (10) and the Back Tube (11) to the Top Panel (4). 4PCS Please note here are two options for you to assemble the cabinet on the Left side or Right side.
-
Page 13: Care And Maintenance
CARE AND MAINTENANCE English - DO NOT EXPOSE THE SURFACES TO DIRECT SUNLIGHT OR EXTREME ENVIRONMENTAL CONDITIONS. ANY DAMAGE RESULTING FROM SUCH EXPOSURE IS NOT COVERED BY THE PRODUCT’S WARRANTY. - THE PREFERABLE METHOD TO CLEAN THE SURFACES IS TO WIPE THEM USING A SOFT CLOTH DAMPENED WITH A SOLUTION SOAP AND WATER, THEN DRY WITH A CLEAN TOWEL.
