Print Option
9. Verify the leading edge of the first label is still behind the tear
bar of the Peel/Tear assembly.
10. Close the printhead by pressing down on both sides of the front
of the pivoting deck and rotating the deck lock
counterclockwise against its stop. This locks the pivoting deck
and printhead assembly into the printing position.
11. Close the front door. The door must be closed for the Label
Sensor to first sense the label and then its removal.
2
12. For automatic label peel-off mode, set Media Handling to Peel-
Off under the MEDIA CONTROL Main menu. See Chapter 3 for
more information on configuring the printer.
13. Close the media cover.
40
1
3
Legend:
1) Pivoting Deck
2) Label Only
3) Deck Lock Lever
