Loading Media And Ribbon

Loading Fanfold Media

1. Open the media cover.
2. Remove any roll media.
3. Slide the media hanger guide outward to the end of the media
hanger, and rotate it downward to a horizontal position.
4. Place the fanfold media either behind or beneath the printer,
depending on the desired fan fold supply location. Insert the
first few labels through either the rear or bottom panel opening.
5. Place the media over the media hanger, flush against the back
of the printer.
6. Rotate the media hanger guide to its upright position and slide
it inward against the outer edge of the loaded media.
32
Legend:
1) Media Hanger Guide
2) Media Hanger
3) Fanfold Media
1
2
3
