5. Manually position the leading edge of the first label to just
behind the tear bar of the Peel/Tear assembly.
6. Thread the liner counterclockwise around the rewinder spindle
and insert the liner end into one of the slots in the rewinder.
7. Rotate the rewinder release lever counterclockwise so it forms
a ridge along the rewinder. (Rotate the rewinder release lever
clockwise to remove media.)
8. With one hand holding the liner in the slot, rotate the rewinder
counterclockwise until the liner is taught on the rewinder
spindle.
1
Legend:
1) Rewinder
2) Rewinder Release Lever
Label Peel Off
2
