Print Option

Print Option

Label Peel Off

The printer can be set up to automatically peel labels of the backing
liner and dispense them one at a time while rewinding the liner.
This configuration requires routing the liner through the rollers on
the Peel/Tear assembly and the use of the internal rewinder.
1. Open the media cover.
2. Open the front cover.
3. Open the pivoting deck by rotating the deck lock lever
clockwise to the end of its travel. The pivoting deck will swing
upward.
4. Thread the liner over the tear bar and around the bottom roller,
then through the slot of the front door and into the printer.
38
1
2
Legend:
1) Tear Bar
2) Bottom Roller
3) Deck Lock Lever
3
