PRECISION DIGITAL Javelin D PD644 Specification Datasheet
High voltage dc meter, 0-300 vdc input, nema 4x, ip65 front, scale in engineering units, sunlight readable led display, 4-20 ma analog output, two form c 3 a relays option, rs-485 serial communications, modbus rtu option, data acquisition with meterview
Hide thumbs
Also See for Javelin D PD644:
- Instruction manual (56 pages) ,
- Instruction manual (56 pages)
Table of Contents
Advertisement
Quick Links
HigH Voltage DC Meter
•
0-300 VDC input
•
NEMA 4X, IP65 front
•
Scale in engineering units
•
Sunlight readable leD display
•
4-20 mA analog output
•
Two form C 3 A relays option
•
RS-485 serial communications
•
Modbus
•
Data acquisition with MeterView
Precision Digital corPoration
Javelin D • Model PD644
rtU option
®
®
www.predig.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PRECISION DIGITAL Javelin D PD644
Summary of Contents for PRECISION DIGITAL Javelin D PD644
- Page 1 Scale in engineering units • Sunlight readable leD display • 4-20 mA analog output • Two form C 3 A relays option • RS-485 serial communications • Modbus rtU option ® • Data acquisition with MeterView ® www.predig.com Precision Digital corPoration...
-
Page 2: Main Menu
JAvElIN D • MoDEl PD644 HIgH volTAgE DC METER EASy SETuP & PRogRAMMINg Main Menu The main menu consists of the three most commonly used The Javelin D is easy to set up and program because functions: Setup, Program, and Password. Press the Menu everything is done using the simple four-button programming button to enter the Programming Mode then press the Up method. - Page 3 JAvElIN D • MoDEl PD644 HIgH volTAgE DC METER Serial Communication (SerL) WiriNg DiagraMS This menu is used to program the Serial communication Voltage input parameters such as the address for each meter when used in The Javelin D is factory calibrated to accept DC voltages a multi-drop mode.
-
Page 4: Ordering Information
JAvElIN D • MoDEl PD644 HIgH volTAgE DC METER FielD eNCloSUreS orDeriNg iNForMatioN The Javelin is available with a wide variety of NEMA 4, Javelin D • Model PD644 NEMA 4X, and explosion-proof enclosures. 85-265 VAC** 12-36 VDC** Options Installed NEMA 4 &... -
Page 5: Specifications
Disclaimer Your Local Distributor is: The information contained in this document is subject to change without notice. Precision Digital Corporation makes no representations or warranties with respect to the contents hereof, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
