The "control menu" can control the inverter operation, as shown in table 6-5
Table 6-5 Inverter control
Item
ON/OFF
Reset restart
Clear
information
Restore
setup
Control menu
ON/OFF
Clear information
Reset restart
Fig 6.11 Control menu
LCD display
ON/OFF control
O N
O F F
Reset restart
Press ENT key to confirm.
Press ESC key to cancel.
Clear all records: confirm?
Press ENT key to confirm.
Press ESC key to cancel.
Restore to default value
Press ENT key to confirm.
Press ESC key to cancel.
Restore setup
Control the ON/OFF of the inverter via
keypad.
Press " " or "
control" interface to select ON or OFF
operation, press "ENT" to confirm. Press
"ESC" key to cancel and return.
Restart the inverter via keypad, reserve
all the setups of the inverter and the
historical records of operation.
Press "ENT" key in "reset restart" key to
restart the inverter and return, the inverter
starts self-inspection; press "ESC" key to
quit and return.
Press "ENT" key in "clear all records"
interface to clear all records, press "ESC"
key to cancel and return.
"Clear information" is to clear all the set
parameters of the inverter and restore to
default settings, while the historical
records of inverter operations will be
maintained.
"Restore setup" is to clear all the set
parameters of the inverter, and
meanwhile, clear all the contents in
"historical records", and restore to the
default setting.
Press "ENT" key to confirm; press "ESC"
key to quit and return.
