Three-phase photovoltaic grid-connected inverter
No Name
1 Display operation panel
2 Surface cover
3 DC input interface
Communication
4
interface
5 AC terminal
6 Hanging slot
7 Handle
8 Safety precautions
9 Nameplate
10 Anti-theft screw hole
Fan installation
11
component
12 DC switch
LED state indicator
Inverter DC input port, connect to PV array
RS485 communication interface and its extension port EXT
Inverter AC output port, connect to public grid
The docking port between inverter master and installation
bracket
The force bearing point when moving the inverter
Indicate the rated inverter parameters
Used to fix the inverter to the installation bracket
Air inlet port, used to fix the fan
Switch on or switch off DC input
12
Product overview
Instruction
