GRANULDISK GD 700 User Manual

Hide thumbs Also See for GD 700:

Advertisement

Quick Links

Download this manual See also: User Manual
GD 700
User manual
Contents
1. TECHNICAL DATA
2. INSTRUCTIONS
................................................................................... .
3. DAILY CLEANING
4. HACCP OPERATIONS AND HYGIENE
DOCUMENTATION
5. TROUBLESHOOTING AND ALARMS
Art. nr: EN162310808
GrANuldisk AB retains the right to make technical changes to the products.
No responsibility is taken for any printing errors.
EN
.............................................................................
............................................................................
.........................................................................
........................
6
8
13
15
17

Advertisement

loading
Need help?

Need help?

Do you have a question about the GD 700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GRANULDISK GD 700

Summary of Contents for GRANULDISK GD 700

  • Page 1 ..................3. DAILY CLEANING ................4. HACCP OPERATIONS AND HYGIENE DOCUMENTATION ................. 5. TROUBLESHOOTING AND ALARMS ......Art. nr: EN162310808 GrANuldisk AB retains the right to make technical changes to the products. No responsibility is taken for any printing errors.
  • Page 2 Jägershillgatan 15 SE-213 75 MALMÖ, Sweden declares that the following machinery: The GRANULDISK system GD 700 Basic conception a) is manufactured in conformity with the Svenska Arbetarskyddsstyrelsens Författningssamling AFS1994:48. This law conforms with the COUNCIL DIRECTIVE of 22 June 1998 concerning harmonisation of member states` legislation for machinery (the Machinery Directive 98/37/EG), with particular reference to Annex 1 concerning the essential health and safety requirements relating to the design and construction of the machinery.
  • Page 3 Gd 900 Granule There is a risk for slipping if Granules are potwashing machine. left on the floor. GrANuldisk AB recommends that you Formaldehyde, which is dangerous if study the manual thoroughly to be sure inhaled, may be formed if the granules that the machine is installed and used cor- catch fire.
  • Page 4 *** 3 - 6 bar required for unit with steam reduction. Gd 700 is supplied with a 2.5 metres electrical cable to be connected to the main switch on the wall. Main switch is not included in the delivery.
  • Page 6 2. Instructions At the start of the day 1. Close the drain valve on the right side of the machine, (image 1) 2. Pour the Granules into the granulate pocket, (image 2). 3. Switch on the main switch. 4. Place the two heavy seals in position. Put the left one in first and then the right so that they overlap, (image 3).
  • Page 7 Preparing utensils Scrape off any loose food remnants before placing utensils in machine (fig. 5). NB! Do not soak. To avoid formation of foam, do not use washing- up liquid. If foam is created, the machine will not perform properly. Loading All potwashing should be carried out in the basket with dirty surfaces facing spray pipes.
  • Page 8 13456 Saucepan and ladle holder (8) Holder for pots, saucepans, bowls and smaller preparation containers. Containers from about 60 mm to 170 mm deep can be washed using this holder in the standard wash basket. ladles, whisks, spatulas and the like can be washed in the net basket in the middle of the holder.
  • Page 9 Language selection 1. Press the STOP button and wait for 3 seconds. 2. Press button (4), “Normal programme selection”, five times. 3. The display shows the following: PMS 654 PMS 654 Language HVID HVID English GRØN GRØN RØD RØD Select Back TRANSPARENT 1 HVID TRYK TRANSPARENT 1 HVID TRYK...
  • Page 10 HACCP Operation and Hygiene documentation tinue without Granules for 30 seconds. The final rinse is set GD 700 meets the most stringent requirements for disinfect- to guarantee a water temperature of 85 °C for 30 seconds. If ing cleaning of items to be washed by guaranteeing a heat...
  • Page 11 3. Daily cleaning The collection and cleaning of granules/ Place the Granule collector in the basket wheel. It is impor- tant that the collector is placed as far forward as possible on the basket wheel. (Image 13) Start the special Granule collecting programme is activated by first pressing the STOP button and then pressing in the normal programme (4) and Granule programme (6) buttons at the same time for three seconds.
  • Page 12 Cleaning • Lift basket wheel out. Remove and clean both coarse sieves (fig 16). • Hose down inside of machine with cold water. • Clean granule grid (fig.17). • Clean bottom sieve. To make cleaning simpler, bottom sieve can be unscrewed if necessary (fig.18, arrow 1). •...
  • Page 13 GD Memo™ GD Memo is an integrated function which informs the user of the machine’s most important maintenance requirements. With GD Memo, it is possible to ensure optimum wash results, avoid stoppages under high loads and maintain the PMS 654 PMS 654 lowest possible operating costs.
  • Page 14 4. HACCP Hygiene and Operation Documentation GDTdirect™ Storing data on an external computer GRANULDISK Documentation Tool, GDTdirect, is an To store complete operating data for the machine, it needs to ® integrated function for the documentation of the dishwashing be connected to an external computer via a serial cable. Soft- machine’s operating parameters and critical hygiene control...
  • Page 15 5. Data is displayed directly on the computer screen: see the figure on the next page. The view is of a fixed size that cannot be changed, and the table headers are in English. The column width can be changed by placing the mouse in the table header and dragging.
  • Page 16 5. Troubleshooting and alarms Error messages Check the following if the utensils are not completely clean: • Are the spray nozzles blocked? All alarms have a unique error code which you can report to • Were the utensils located correctly? service staff when you contact them.
  • Page 17 Error code Meaning Cause Remedy Long wash tank filling The level sensor in the wash tank has Contact a service engineer! time not been activated within 20 minutes of the solenoid valve opening, the pro- gramme is cancelled. Long rinse tank filling The level sensor in the rinse tank has Contact a service engineer! time...
  • Page 18 Notes...
