GRANULDISK GD 700 User Manual

Hide thumbs Also See for GD 700:

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
GD 700
Usermanual
Contents
Art. nr 16025/ 08.2003/ EN
Granuldisk AB retains the right to make technical changes to the products.
No responsibility is taken for any printing errors.
.....................................................................................
...............................................................................................
.....................................................................................
......................................................................
EN
6
8
13
15

Advertisement

loading
Need help?

Need help?

Do you have a question about the GD 700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GRANULDISK GD 700

Summary of Contents for GRANULDISK GD 700

  • Page 1 Contents 1. TECHNICAL DATA ..................2. INSTRUCTIONS ....................3. DAILY CLEANING ..................4. TROUBLESHOOTING ..............Art. nr 16025/ 08.2003/ EN Granuldisk AB retains the right to make technical changes to the products. No responsibility is taken for any printing errors.
  • Page 2 Jägershillgatan 15 S-213 75 MALMÖ, Sweden declares that the following machinery: The Granuldisk system GD 900 Basic conception a) is manufactured in conformity with the Svenska Arbetarskyddsstyrelsens Författningssamling AFS1994:48. This law conforms with the COUNCIL DIRECTIVE of 22 June 1998 concerning harmonisation of member states` legislation for machinery (the Machinery Direc- tive 98/44/EG), with particular reference to Annex 1 concerning the essential health and safety requirements relating to the design and construction of the machinery.
  • Page 3 This instruction manual is your guide to risk for scalding the correct use of the GD 700 granule pot- washing machine There is a risk for slipping if granules are left on the fl...

  • Page 4: Technical Data

    1. Technical data Weight..........435 kg fi lled machine Tank volume ........83 litres Amount of granules ....8 kg Wash water temperature ..65°C Rinse water temperature..85°C Rinse water volume ....8 litres per wash programme Wash programme......Normal 3 min, 50 s. Long 6 min, 50 s.

  • Page 6: Instructions

    2. Instructions At the start of the day Switch on mains switch on right-hand side of machine. Close outfl ow tap on right-hand side of machine (fi g. 1). Pour granules into granule receptacle (fi g. 2)). Insert the two coarse fi lters. Insert left one fi rst, then right one, which should overlap the fi...
  • Page 7 Preparing utensils Scrape and rinse off any loose food remnants before placing utensils in machine (fi g. 5). NB! Do not soak. To avoid formation of foam, do not use washing-up liquid. If foam is created, the machine will not perform properly. Loading All potwashing should be carried out in the basket with dirty surfaces facing spray pipes.
  • Page 8 GD 750 Saucepan and ladle holder (8) Holder for pots, saucepans, bowls and smaller preparation containers. Containers from about 60 mm to 170 mm deep can be washed using this holder in the standard wash basket. Ladles, whisks, spatulas and the like can be washed in the net basket in the middle of the holder.
  • Page 9 Control panel Button ‘?’ This button is used to alter the settings, for example, from Programme 1 to Programme 2 etc. It is also used to answer ‘No’ to questions on the display window. Button ‘START’ This button starts the wash programme or other events described on the display.
  • Page 10 The guarantee only applies if The machine can now be loaded again and the next programme run. granules from Granuldisk AB are used in the machine. The plastic Close the hood if another wash programme is not being run at once.

  • Page 11: Daily Cleaning

    3. Daily cleaning Collecting and cleaning granules Place granule collector on basket wheel. It is important that the collector is at the front of the basket wheel. (fi g. 13) Start G4, the special granule-collection programme. Take the granule collector out and place it in a sink. Rinse with clean water while stirring.
  • Page 12 Cleaning • Lift basket wheel out. Remove and clean both coarse sieves (fi g 16). • Hose down inside of machine with cold water. • Clean granule grill (fi g.17). • Clean bottom sieve. To make cleaning simpler, bottom sieve can be unscrewed if necessary (fi...

  • Page 13: Troubleshooting

    4. Troubleshooting If pots are not completely clean, check the following: • is there a blockage in the spray nozzles? • were the pots put into the machine and fastened correctly? • was the correct programme selected? • is the dishwater extremely dirty? •...
  • Page 14 Notes...
