Introduction
This manual describes the setup and operation of the S5U13781R00C100 reference board.
The reference board is designed as an evaluation platform for the S1D13781 Display Controller. The
S5U13781R00C100 reference board has host controller connector, LCD panel connector, clock generator,
SPI flash memory (16Mbit), power regulation circuit for S1D13781 core and DC/DC converter for LED
back light.
This user manual is updated as appropriate. Please check the Seiko Epson Website at
http://www.epson.jp/device/semicon_e/product/lcd_controllers/index.htm
for the latest revision of this
document before beginning any development.
We appreciate your comments on our documentation. Please contact us via email at
documentation@erd.epson.com.
X94A-G-004-01
S5U13781R00C100 Reference Board User Manual
Issue Date: 2012/03/26
Revision 1.0
Seiko Epson Corporation
