Main menu item
Topvex FC
125918
Sub-menu item 1 Sub-menu item 2
Outdoor
comp.Setp.
–20°C = 0 m³/h
0°C = 0 m³/h
Act.
m³/h
Flow control
EAF
Actual: xxx
m³/h
Setp.:xxx m³/h
Flow control EAF
Setp 1/1:
m³/h
Setp 1/2:
m³/h↓
Outdoor
comp.Setp.
–20°C = 0 m³/h
0°C = 0 m³/h
Act.
m³/h
Pressure
control SAF
Actual: Pa
Setp.: Pa
Pressure control
SAF
Setp 1/1:
Pa
Setp 1/2:
Pa
Explanations
Set the SAF airflow
compensation for the settable
outdoor temperature. The
outdoor compensation is linear
and is set using two parameter
pairs which give the value of the
compensation at two different
Comp: 0
outdoor temperatures. The
compensation can be positive
or negative.
Shows the actual airflow
compensation.
Airflow for the extract air fan
(constant airflow control).
Only visible if the unit is
configured for "Flow control"
(CAV).
Set the normal (1/1) and
reduced (1/2) airflow for the
1100
extract air fan.
550
Set the EAF airflow
compensation for the settable
outdoor temperature. The
outdoor compensation is linear
and is set using two parameter
pairs which give the value of the
compensation at two different
Comp: 0
outdoor temperatures. The
compensation can be positive
or negative.
Shows the actual airflow
compensation.
The actual external pressure
and set point for the supply air
fan.
Only visible if the unit is
configured for "Pressure
control" (VAV)
Set the external pressure set
point for normal speed (1/1)
and reduced speed (1/2) for the
200
supply air fan.
100
