Main menu item
→Temperature
Topvex FC
125918
Sub-menu item 1 Sub-menu item 2
Fire damper
function
Not active
Operation when
alarm
Stopped
Frost protection
Active
Cooling recovery
Yes
External set
point
Not active
→ Alarm events
→AI
→Input/Output
→AI exp3
→DI
→UI
→UI exp3
→AO
→DO
Extract air
temp
Actual: ºC
Setp: 22.0ºC
Explanations
Status of the fire damper
function when fire alarm is
active.
Status of the frost protection
function.
Status of the cooling recovery
function.
Status of the external set point.
Alarm log list along with the time
and date they occurred.
Move down and up in the list by
pressing ↑↓.
Status of the Analogue inputs.
Status of the Analogue inputs
for expansion unit.
Only visible for
counter-/crossflow units
with a connected pressure
module
Status of the Digital inputs.
Status of Universal Analogue
inputs or Universal Digital
inputs.
Status of the Universal Analogue
inputs for expansion unit.
Only visible for
counter-/crossflow units
with a connected pressure
module
Status of the Analogue outputs.
Status of the Digital outputs.
Configured temperature control
(default is Extract air
temp).
Actual temperature in the
chosen control mode.
Set-point temperature for the
chosen control mode.
