SystemAir Topvex SR 11 Series Installation Instructions Manual
Compact air handling units
Hide thumbs
Also See for Topvex SR 11 Series:
- Operation and maintenance instructions (34 pages) ,
- Operation and maintenance (20 pages) ,
- Manual (20 pages)
Related Manuals for SystemAir Topvex SR 11 Series
Summary of Contents for SystemAir Topvex SR 11 Series
- Page 1 Topvex SR 09, 11, Topvex TR 09-15 Compact Air Handling Units Installation instructions Document in original language | 125593 · A003...
- Page 2 © Copyright Systemair AB All rights reserved E&OE Systemair AB reserves the rights to alter their products without notice. This also applies to products already ordered, as long as it does not affect the previously agreed specifications. 125593 | A003...
-
Page 3: Table Of Contents
Contents EU Declaration of conformity......1 Warnings............2 Product information .........2 General ..........2 Technical data ........3 3.2.1 Dimensions and weights Topvex SR 09, 11 .......3 3.2.2 Dimensions and weight Topvex TR 09-15 .......4 3.2.3 Electrical data ......5 Transport and storage ......6 Installation.............6 Unpacking ..........6 Where/how to install ......6 Dividing the Topvex air handling... -
Page 5: Eu Declaration Of Conformity
EU Declaration of conformity | EU Declaration of conformity Manufacturer Systemair Sverige AB Industrivägen 3 SE-739 30 Skinnskatteberg SWEDEN Office: +46 222 440 00 Fax: +46 222 440 99 www.systemair.com hereby confirms that the following products: Air handling units None... -
Page 6: Warnings
| Warnings Warnings The following admonitions will be presented in the different sections of the document. Danger • Make sure that the mains to the unit is disconnected before performing any maintenance or electrical work! • All electrical connections must be carried out by an authorized installer and in accordance with local rules and regulations. -
Page 7: Technical Data
Product information | Technical data 3.2.1 Dimensions and weights Topvex SR 09, 11 15R½" Fig. 1 Dimensions (mm) Topvex SR 09, 11 (Drawn as left hand unit) Model SR09 1120 SR11 1230 Model Weight, kg SR09 SR11 125593 | A003... -
Page 8: Dimensions And Weight Topvex Tr 09-15
| Product information 3.2.2 Dimensions and weight Topvex TR 09-15 Fig. 2 Dimensions (mm) Topvex TR 09-15 (Drawn as left hand unit) Model TR09 1790 1630 1120 TR12 1930 1740 1230 TR15 1930 1980 1470 1180 Model Weight, kg TR09 1030 TR12 1140... -
Page 9: Electrical Data
Product information | 3.2.3 Electrical data Model Fans (W tot) 400 V El Heating battery Fuse (mains) (A) for Fuse (mains) (A) (kW tot.) 400 V 3N~ for 230 V 3~ SR09 EL 5062 3x32 3x50 – 5062 3x10 3x16 SR09 (None, HWL/HWH) SR09 EL M0 3754... -
Page 10: Transport And Storage
Unpacking Verify that all ordered equipment are delivered before starting the installation. Any deviation from the ordered equip- ment must be reported to the supplier of Systemair products. Where/how to install Place the unit on a horizontal flat surface. It’s important that the unit is completely levelled before it is put into operation. -
Page 11: Dividing The Topvex Air Handling Units
Installation | Dividing the Topvex air handling units On delivery the two halves of the Topvex appliance are mounted together. If necessary they can be divided for easy transport to the site of installation figure 3 and figure 4. 4.3.1 How to split the Topvex SR unit Remove the heat exchanger, supply air fan and the extract air filter A. -
Page 12: How To Split The Topvex Tr Unit
| Installation 4.3.2 How to split the Topvex TR unit Remove the heat exchanger, extract fan and the extract air filter A. Remove the plate B. Loose the cable connectors C. Remove the 7 M10 screws that join the two halves of the appliance Fig. -
Page 13: Installing The Unit
Installation | Installing the unit The unit must be installed in the following position (figure 5 and figure 6). Fig. 5 Installation position (left hand unit) Fig. 6 Installation position (right hand) Table 1 Symbol description Symbol Description Supply air Exhaust air Outdoor air Extract air... -
Page 14: Installation Procedure
| Installation 4.4.1 Installation procedure 1 Prepare the surface where the unit is to be mounted. Make sure that the surface is flat, levelled and that it supports the weight of the unit. Perform the installa- tion in accordance with local rules and regulations. 2 Lift the unit in place. -
Page 15: The Rotors Vertical Position (Topvex Sr 09, 11)
Installation | 4.4.2 The rotors vertical position (Topvex SR 09, 11) To achieve optimal sealing against the rotor's brush strip and the chassits frame, check and if necessary adjust the ro- tors vertical position when the unit is installed. Remove the filter for easy access. Fig. -
Page 16: Supply Air Sensor (Topvex Sr 09, 11)
| Installation Supply air sensor (Topvex SR 09, 11) The supply air sensor is fitted in the duct ca. 3 m after the unit in the supply air duct (figure 8). See chapter 4.6.6 to which terminals the sensor needs to be connected in the electrical connection box. Other temperature sensors are built in to the unit from factory. -
Page 17: Connections
Installation | Connections 4.6.1 Ducting Fig. 9 Connections and basic components in left hand connected units Description Symbol Position Connection supply air Connection exhaust air Connection outdoor air Connection extract air Fan supply air Fan extract air Filter supply air Filter extract air Heat exchanger Rotor motor... -
Page 18: Silencers
| Installation 4.6.3 Silencers To avoid fan noise being transferred via the duct system, silencers should be installed both on supply and extract air. To avoid noise being transferred between rooms via the duct system and also to reduce noise from the duct system it- self, installation of silencers before every inlet diffuser is recommended. -
Page 19: Electrical Connection Box, Components
Installation | 4.6.5 Electrical connection box, components Topvex SR/TR are equipped with a built in regulator and internal wiring (figure 11). The figure shows the electrical connection box for the Topvex TR 09-15 units. The connection box for the Topvex SR 09, 11 has the same layout and components with the difference that the electrical heater is situated in a separate compartment. -
Page 20: External Connections
| Installation 4.6.6 External connections Table 2 Connections to external functions Terminal block Description Remark Ground Earthed neutral (supply voltage) Used for phase 230V 1~ and 400V 3~ Used for phase 230V 1~ if the Phase (Main supply voltage) unit has this mains 400V 3~/230V 3~ Phase (Main supply voltage) 400V 3~/230V 3~... - Page 21 Installation | Communication possibilities for controller E283 WEB. • RS485(Modbus): 50-51-52 or 60-61-62 • RS485(BACnet): 50-51-52 or 60-61-62 • RS485(Exoline): 50-51-52-53 or 60-61-62-63 • TCP/IP Exoline • TCP/IP Modbus • TCP/IP WEB • TCP/IP BACnet Fig. 12 BMS connection on the controller 125593 | A003...
-
Page 22: Installing The Control Panel
| Installation Installing the control panel 4.7.1 Dimensions Fig. 13 Control panel dimensions Dimensions (mm) Position 115.0 94.0 26.0 c/c 60.0 50.5 4.7.2 General information The control panel is delivered connected to the Corrigo control unit situated in the electrical connection box. Cable length is 10 m. -
Page 23: Installation
Installation | 4.7.3 Installation 1. Find an appropriate place to install the control panel. Maximum length between control panel and unit is 100 m. 2. If needed, drill two holes in the wall to hang the control panel (center to center: 60 mm) (pos.1, figure 14). Fig. - Page 24 Systemair Sverige AB Industrivägen 3 SE-739 30 Skinnskatteberg, Sweden Phone +46 222 440 00 Fax +46 222 440 99 www.systemair.com...
