Revolution HVLS Fan • Rogue
®

INSTALLATION

Components
Before installation, verify all components were received
Notify your Rite‑Hite representative if parts are missing
or damaged
• 1 box: Motor, hub assembly, remote mounted control
switch and disconnect switches. ≈ 160lb [73kg]
• 1 box: Mounting hardware and cables. ≈ 50lb [23kg]
• 1 box: Control box. ≈ 35lb [16kg]
• Revolution Fan: 4 blades
• Rogue Fan: 2 blades
Required Tools
7/16in wrenches
2
1/2in wrenches
2
2 9/16in wrenches
3/4in wrenches
2
1 Vice grip
Flat screwdrivers (large and small)
2
Small standard screwdriver
1
1 Medium Phillips screwdriver
1 Torque wrench, minimum 200‑ft‑lb (270 Nm), 1/2in drive
1 1/2in to 3/4in socket adapter
1 1/2in socket extender
1 Metric 7mm deep well socket – or Driver
1/4in cable cutter
1
Crimp on ring terminals, M4 (#8) stud, for motor wiring
4
Torpedo level
1
Drill and 1/2in drill bit If mounting to support angles that
1
span building joists
4
HVLS Fan
®
Installation/Service/Owner's Manual
(1 can be socket/driver)
Specifications
Diameter (Ø) 8ft, 12ft, 16ft, 20ft and 24ft
[2440mm, 3660mm, 4880mm,
6100mm and 7320mm]
Blades Aluminum
Blade Finish Mill-finish standard,
custom colors optional
# of Blades 2 (Rogue) or 4 (Revolution)
Watts 75 (@ 10Hz) to 1750 (@ 60Hz) Typical
Frequency 50/60 Hz
Coverage Up to 22,000sq ft [2046m
center in all directions
Decibels 40 to 63 dBA depending on fan speed
(measured 20ft [6100mm] below and 20ft [6100mm]
from the fan's center)
Air Speed Up to 7mph [3m/s] at full speed
Controls Variable speed
Mounting 10ft - 80ft [3m - 24m] from finished floor to bottom of
Heights blade
Fan Ø RPM
8ft [2440mm] 30‑150
12ft [3660mm] 18‑96
16ft [4880mm] 15‑74
20ft [6100mm] 12‑59
24ft [7320mm] 10‑52
Revolution and Rogue
2 HP (1.5 kW)
Fan Input Current (Amps)
Control Box Fuse Rating
(Amps)
Minimum Service Amps
Maximum Number of Fans per Branch Circuit
15
20
Branch
25
Circuit
30
Amps
35
40
] 85ft [26m] from the fan's
2
Weight
268lb [122kg]
276lb [125kg]
284lb [129kg]
292lb [132kg]
300lb [136kg]
Supply Voltage
200‑240V 200‑240V 400‑480V
1 ɸ 3 ɸ 3 ɸ
13 7
20 15
20 15
NA 1
1 2
1 2
1 3
2 4
2 4
Publication: AMEN00064 2019‑03‑07
Rite‑Hite
®
35
10
10
3
4
5
6
8
9
