INSTALLATION
Step 4 – Safety Cables
WARNING / AVERTISSEMENT
Always use safety cables. They protect against a
fan fall in the event of a bolted joint loosening.
Toujours utiliser des câbles de sécurité. Ils
protègent contre la chute d'un ventilateur dans le
cas d'un relâchement de l'assemblage boulonné.
10
HVLS Fan
®
Installation/Service/Owner's Manual
(INCLUDED WITH KIT)
Figure 7
1 Wrap a safety cable around the bolted brackets at the
ceiling and through the top of the extension tube (A)
2 If installing with adjustable‑length extension tubes,
use a third safety cable to secure the center bolted
joint of the extension tubes (B)
3 Wrap a second safety cable through the bottom
of the extension tube and through the top of the
motor housing (C)
4 Secure the safety cables with the provided clamps
