Technical data

8
Performance specifications and guarantee only in connection with original spare and
replacement parts!
8.1

miniDrive

Supply voltage
Max. welding current (100% DC)
Max. welding current (60% DC)
Wire feed speed
Standard roll installation
Drive rolls
Euro torch connector
Protection classification
Ambient temperature
EMC class
Safety identification
Harmonised standards used
Dimensions L x W x H
Weight excl. hose package
099-005262-EW501
22.11.2016
60 VDC
300 A
400 A
1 m/min–20 m/min
1.0 + 1.2 mm (for steel wire)
37 mm
Euro torch connector
IP 23
-25 °C to +40 °C
A
/
IEC 60974-1, -5, -10
300 mm x 180 mm x 200 mm
7.5 kg
Technical data
miniDrive
31
