5.6

Setting the operating point (welding output)

The operating point (welding power) is specified using the MIG/MAG one-knob operation principle, i.e. the
user can specify either the welding current, the wire feed speed or the material thickness to define the
operating point. The electronic system calculates the optimal required welding voltage value.
Operating
element
The arc length can be corrected as follows.
Operating
element
099-005262-EW501
22.11.2016
Action Result
Operating point setting via wire speed.
Action Result
Arc length correction
Design and function
Setting the operating point (welding output)
