Parameter input
specification limits
J
08.01.2008 Retsch GmbH

EasySieve

Control, evaluation, documentation

EasySieve , the software for grain size analysis from
RETSCH, is far superior to manual evaluation in many re-
spects. This is because the software is able to carry out
the measuring and weighing operations automatically –
from registering the weights of the sieves up to evaluation
of the data. This can be accomplished more easily and
more conveniently than ever before – hence „easy".
The software design is self-explanatory and corresponds to
the logical sequence of a grain size analysis. Therefore the
learning phase can be kept very short. The large number
of evaluation possibilities also permits absolute flexibility
with regard to the adaption to sophisticated individual
problems.
Trend analysis of product processes
PC – serial connection
The AS 200 tap can be connected serially with a PC for data
acceptance and data transfer. For this a commercial 9-pole
RS232 cable, included with the AS 200 tap, is used. In this way
communication with the EasySieve
able as an accessory) is possible.
Remove the cap which protects the connection from dust
and moisture when not used
Connect connection J with the PC through the serial ca-
ble
20
Comparison with
®
evaluation software (avail-
Doc.Nr. D 98.025.9999
