Operation of the AS 200 tap

Switching on and off

The main switch is located on the rear left side of the
AS 200 tap
Switch on the main switch
- -
lights up in the display time min
The LED STOP lights up
The AS 200 tap is now without an interval and is
ready for functioning in continuous operation at a
speed of 50 min

Display and operating element

The button + increases the sieving time in the range
f rom 1 – 99 min.
The button – reduces the sieving time and is shown
in the display in the range from 1 – 99 min.
Set continuous operation is shown with - - in the
display.
Press the START button to start the sieving opera-
tion. The green LED lights up.
The sieving operation is ended with the STOP button
and the red LED lights up.
Setting the time and continuous
operation
When switching on the AS 200 tap the sieving tme
is undetermined.
Two dashes
Increasing the time:
Button 13 increases the time up to 99 minutes.
Reducing the time:
Button 12 reduces the time down to a value of one
minute.
Continuous operation:
If the time drops below one minute two dashes ap-
pear in the display. This activates continuous opera-
tion. This also applies when 99 minutes are ex-
ceeded.
15
-1
.
- -
are shown in the display 13.
