Daikin FVXS25FV1B Service Manual page 20

Removal of Fan Rotor / Fan Motor
Step
3 Unfasten the 2 hooks
to remove the harness
retainer and remove
the fan motor.
3. Remove the casing.
1 Remove 3 screws and
unfasten the 2 hooks to
remove the upper
casing.
2 Remove 2 screws and
unfasten the 2 hooks to
remove the right casing
or the left casing.
18
Procedure
Fan motor
Harness
retainer
Hook
Hook
Points
Hook
(R14976)
Press the 2 hooks toward
the back side and remove
the casing.
(R14758)
Press the 2 hooks toward
the back side and remove
the casing.
Hook
(R14759)
Removal Procedure
Si061061
