Daikin FVXS25FV1B Service Manual page 16

Removal of Vertical Blades
Step
5 Remove the 2 screws
to remove the swing
motor.
2. Remove the vertical blade
(lower).
1 Remove the 2 screws.
2 Remove the drain hose
and release the harness
of the lower air outlet
motor from the hook.
14
Procedure
Swing motor
Drain hose
(R6807)
Shaft
(R6808)
Be careful not to wet the
floor with drained water.
(R6809)
Hook
(R6810)
Si061061
Points
Removal Procedure
