Olivetti Fax-Lab 200 Instruction Manual page 18

n o t e
If you have entered any incorrect digits: position the cursor,
using the |/} keys, to the incorrect digit and overwrite it with
the correct one; if you want to delete the number altogether,
press the key.
n o t e
If you want you can dial the correspondent's number using
the quick dialling procedures, see "To set one-touch and
speed dialling", "To send a document with one-touch
dialling" and "To send a document with speed dial-
ling".
n o t e
If you want to abort the transmission in progress, press
the key. The fax machine unloads the document from
the ADF and returns to the initial stand-by mode.
If the document to be removed consists of more than one
sheet, before pressing
the others by hand.
T
O HEAR THE DIALLING TONE WHEN SENDING A DOCUMENT
Place the document in the ADF. The display shows the
default contrast and resolution values: NORMAL and
(standard), respectively.
If you want, change the contrast and resolution values as
described previously.
To hear the dialling tones. The display shows:
TYPE NUMBER
On the numeric keypad type the number of the correspond-
ent to whom you want to send the document (max. 52
digits).
As soon as you hear the tone of your correspondent's fax
machine, press
If the document is sent correctly, once this operation has
been completed, the display will show the message "TX
COMPLETED" for a few seconds.
T
O SEND A DOCUMENT WITH THE RECEIVER RAISED
Place the document in the ADF. The display shows the
default contrast and resolution values: NORMAL and
(standard), respectively.
If you want, change the contrast and resolution values as
described previously.
Lift the receiver to engage the line. The display shows:
TEL CALL
On the numeric keypad type the number of the correspond-
ent to whom you want to send the document (max. 52
digits).
10
to unload the first, remove all
to start sending the document.
If your correspondent's fax machine is set up for auto-
matic reception, you will hear the fax machine signal.
If it is set up for manual reception, the correspondent
himself will answer so you can ask him to press the start
key on his fax machine, after which you will hear the fax
machine signal.
To start sending.
If the document is sent correctly, once this operation has
been completed, the display will show the message "TX
COMPLETED" for a few seconds and then the initial stand-
by status.
n o t e
If you forget to hang up after completing the transaction, the
fax machine will emit a beep to prompt you to hang up.
A
UTOMATIC REDIAL
If no connection is established due to line errors or because the
correspondent's number is busy, the fax machine automatically
redials the number up to three times.
T
O CALL THE CORRESPONDENT AGAIN WITHOUT HAVING TO
DIAL HIS NUMBER MANUALLY
The fax machine always saves the last number dialled, which you
may therefore redial by pressing the
T
O DIAL A FREQUENTLY USED CODE AUTOMATICALLY
Once programmed to do so (see "To set it up for the first time",
section "Preliminary operations"), the fax machine will allow you to
store a frequently used code such as an area code or a code for
access to an alternative telephone operator.
Automatic code dialling is activated by pressing the
dialling the correspondent's number.
If the fax machine is connected to a private line (PBX) , the
is to be pressed twice before dialling the correspondent's number.
T
O SEND A DOCUMENT AT A PRESET TIME
)
TRANSMISSION
This function enables you to solve time zone problems if
your correspondent is located thousands of kilometres away
and to avoid paying high prices by choosing time bands
when there is less traffic on the telephone lines.
Place the document in the ADF. The display shows the
default contrast and resolution values: NORMAL and
(standard), respectively.
key twice.
key before
key
(
BROADCAST
