V100 GNSS RTK System Getting Started
V100 GNSS RTK System
Getting Started
Co., Ltd
Hi-Target
Surveying Instrument
All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hi-Target V100

Summary of Contents for Hi-Target V100

  • Page 1 V100 GNSS RTK System Getting Started V100 GNSS RTK System Getting Started Co., Ltd Hi-Target Surveying Instrument All Rights Reserved...

  • Page 3: Table Of Contents

    V100 GNSS RTK System Getting Started Content ------------------------------------------------------------------------------ 3 1. Products Introductions -------------------------------------------------------------------------------- 4 1.1 Hardware structure ---------------------------------------------------------------------------- 5 1.2 Power supply system ---------------------------------------------------------------------------------- 9 1.3 Button operation --------------------------------------------------------------------------------------------------- 10 1.4 LED ------------------------------------------------------------------ 12 1.5 Handheld controller iHand20 --------------------------------------------------------------------------- 19 2.
  • Page 4 V100 GNSS RTK System Getting Started 4. Trouble Shooting ------------------------------------------------------------------------------------ 59 4.1 Registration procedure -------------------------------------------------------------------------- 60 4.2 Firmware upgrade -------------------------------------------------------------------------------- 62 4.3 Reset operation ----------------------------------------------------------------------------------- 63 Schedule1 factory default parameters ------------------------------------------------------------63 Schedule2 key accessories information -------------------------------------------------------- 64 Ⅱ...
  • Page 5 V100 GNSS RTK System Getting Started Preface Introduction Welcome to use Hi-Target V100 receiver, this introduction is applicable to Hi-Target V100 products. The introduction describes how to install, set and use V100 products. Experience requirement In order to help you use Hi-Target series products better, Hi-Target suggests you carefully reading the instruction.
  • Page 6 2.Log in Hi-Target official website, download the electronic version introduction in “Download Center” → “Manual” → “Surveying Products” Advice If you have any advice or suggestion on V100, please call us or Dial the national hotline: +86 400-678-6690. Your feedback information will improve the production quality.

  • Page 7: Products Introductions

    V100 GNSS RTK System Getting Started C C C C H H H H A A A A P P P P T T T T E E E E R R R R Products Introductions ■ Hardware structure ■ Power supply system ■...

  • Page 8: Hardware Structure

    Products Introductions 1.1. Hardware structure The product appearance is divided into three parts, upper cover, bottom cover and control panel. Upper cover Control panel Bottom cover Figure 1-1-1 Raised point Guard collar Figure 1-1-2...

  • Page 9: Power Supply System

    V100 GNSS RTK System Getting Started Five-pin socket Battery compartment Connection screw Mini USB socket Protective plug Figure 1-1-3 ◆ Connection screw: for the instrument fixed to the base or the pole. ◆ Battery compartment: for housing lithium battery. ◆ Five-pin socket: for external data linking and external power supply.
  • Page 10 Products Introductions Lithium battery Figure 1-2-1 Adapter Figure 1-2-2 Recharge V100 lithium battery should be charged by PSAI10R-050Q adapter, about 7 hours of charging time.
  • Page 11 V100 GNSS RTK System Getting Started Warning: 1. Only the battery and charger configured by the manufacturer can be used; the battery must not be thrown into fire or used in metal short circuit electrode. 2. Stop using when the battery is heating, deformation, liquid leakage, smelling or other abnormal reactions, please exchange new battery.
  • Page 12 Products Introductions Battery pole Metal button Figure 1-2-4 Figure 1-2-5 (3) Close the battery cover. Removal Push up the battery cover button to open it, then press the metal button and remove battery.

  • Page 13: Button Operation

    V100 GNSS RTK System Getting Started Power supply Power supply mode Internal：lithium battery Power supply mode External：USB, Five-pin socket Power supply USB socket：DC power 4.2-5.5V/1.5A External power supply request Five-pin socket：DC power 6-28V/1A When external power supply, the host will automatically detect the voltage of lithium battery and external power supply, and choose the higher voltage power.

  • Page 14: Led

    Products Introductions Description of power button operation Operation name Description Shutdown status, long press the button one second to boot, all lights are on Boot status, long press the button three seconds, all lights double fast flash, release the button Shutdown status, long press the button six seconds, all lights Automatic setting station double fast flash, release the button, the instrument will...
  • Page 15 V100 GNSS RTK System Getting Started LED Function Description Meaning Power LED Full battery Long-term lighting (Green) Full battery voltage: internal battery≥3.9V（100% Power LED Long-term lighting (Yellow) power） Normal voltage: 6% <internal battery power ≤99% Long-term lighting Low voltage: internal battery≤5%...

  • Page 16: Handheld Controller Ihand20

    Products Introductions 1.5. Handheld controller iHand20 Front of handheld controller The front of iHand20 handheld controller includes touch screen, keyboard and microphone Touch screen Keyboard Microphone Figure 1-5-1 ◆ Touch screen: Multipoint capacitive touch screen with touch pen, which supports Chinese and English input.
  • Page 17 V100 GNSS RTK System Getting Started Reverse side of handheld controller There are camera, battery cover, belt, speaker, etc. on the reverse side of iHand20 handheld controller. Speaker Camera Battery cover NFC module Belt Figure 1-5-2 ◆ Camera: Used for field collection of image information.
  • Page 18 Products Introductions Side of handheld controller Waterproof & dustproof rubber cover Audio port Mini USB Figure 1-5-3 ◆ Mini USB: Used for connecting USB data line and iHand20 handheld controller. ◆ Audio port: Used for connecting headphone cable and iHand20 handheld controller. Warnings: In case of not using audio port or Mini USB, please close the rubber cover so as to achieving waterproof and dustproof.
  • Page 19 V100 GNSS RTK System Getting Started Battery (Lithium battery: 3.7V /6300mAh) Figure 1-5-5 Data line Figure 1-5-6 It is used for changing and exchanging data between computer. Touch pen Figure 1-5-7 To use the touch pen to operate the handheld controller, it is required to start the function of "handwriting pen", and open the handheld controller’s [system setting] →...
  • Page 20 Operation of handheld controller Keyboard Most settings and operations of Hi-Target iHand20 handheld controller can be completed by the touch pen, and commonly used operations can be completed by keyboard. Appearance and functions of keyboard are introduced briefly as follows.
  • Page 21 V100 GNSS RTK System Getting Started Cautions: When installing Hi-Survey Road for the first time, it is necessary to press button APP for 3s for software quick start selection settings. Otherwise, corresponding software cannot be started quickly by only pressing button APP.
  • Page 22 Products Introductions Cautions: 1. When the iHand20 handheld controller is not used in the work, please turn off the backlight for saving electric quantity and prolonging the working time. 2. Only the image collection interface supports the shortcuts operation. In order to avoid the input conflict of input box, the text interface does not support shortcuts operation.

  • Page 23: Technical Parameters

    V100 GNSS RTK System Getting Started C C C C H H H H A A A A P P P P T T T T E E E E R R R R Technical Parameters...
  • Page 24 Technical Parameters GNSS configuration Table 1 GNSS configuration International first-class PCC new efficient intelligent real-time System core core Channel B1, B2 L1 C/A, L2E, L2C, L5 L1 C/A, L1 P, L2 C/A（Limited GLONASS M and L2P） GLONASS Upgrade reserve GALILEO ASCⅡ：NMEA-0183 and binary : Trimble GSOF Output format sCMRx, CMR, CMR+, RTCM2.1/2.2/2.3/3.0/3.2...
  • Page 25 V100 GNSS RTK System Getting Started System configuration ◆ Operation system：intelligent real-time system ◆ Boot time: 1s ◆ Data storage：built-in 8GB storage Built-in communication ◆ NFC near field communication ◆ Dual mode Bluetooth communication Control panel ◆ Panel: one button ◆...
  • Page 26 Technical Parameters Environment characteristics ◆ Protection class：IP67; protect 2m temporary soaking underwater, completely prevent dust ◆ Shock-proof: Anti 2 m natural fall ◆ Working temperature: -40 ℃ ~ 65℃ ◆ Storage temperature: -40℃～75℃ ◆ Relative humidity: 100%, anti-condensation Private cloud service The cloud service supports for 24 hours, realizes integrated technique of indoor work and field work, remote manage serve and support equipment.
  • Page 27 V100 GNSS RTK System Getting Started Electronic jamming The receiver shall not be installed in the place near to strong electric power and interference signal, such as: ◆ Oil duct (spark plugs) ◆ Telvision and computer display ◆ Generator ◆ Battery-operated motor cycle ◆...

  • Page 28: Work Modes Introdution

    Work Modes Introducation C C C C H H H H A A A A P P P P T T T T E E E E R R R R Work Modes Introduction ■ Static mode ■ Network rover mode ■...

  • Page 29: Static Mode

    3.1. Static mode 3.1.1. Static data collection V100 GNSS Receiver can collect static data. Relative operations are as below. 1. Set up receiver on a control point, centering and leveling strictly. 2. Measure the height of receiver for three times, on condition that the difference of each measuring is less than 3mm and the final height of the receiver should be the average height.

  • Page 30: Static Data Storage And Download

    2) V100 GNSS receiver doesn’t support recording Rinex format data. 3.1.2. Static data storage and download Collected GNSS static data is stored in "static" disk that 8GB internal storage of V100 receiver, effective storage space is 6.6GB, includes two folders: log and gnss, log folder stores log information, the data format storage in gnss folder is * .gns.
  • Page 31 V100 GNSS RTK System Getting Started The receiver can download data like U disk , it need Mini USB data cable, one end of Mini USB data cable is connected to computer USB port and the other end is connected to Mini USB port of receiver.

  • Page 32: Network Rover Mode

    Work Modes Introducation 3.2. Network rover mode Pair with the powerful surveying software Hi-Survey, the intelligent V100 GNSS receiver will turn into a portable network rover. The main operating procedures in brief: ◆ Project setting ◆ Data collecting ◆ Staking out ◆...
  • Page 33 V100 GNSS RTK System Getting Started 1. New project can be built and the existing project can be opened or deleted. 2.Input project name. (Note: The name of new project shall not be the same as the name of old projects.)
  • Page 34 Work Modes Introducation For measurement, coordinate system must be configured, because it is related to the accuracy of coordinate. There are two methods to set the coordinate system. 1. Click Project Settings：Including settings of project and coordinate system information. 2. Settings interface.
  • Page 35 V100 GNSS RTK System Getting Started (1) Build a coordinate system 1. Click ① to enter into the setting interface. 2. Select a coordinate system from “Predefined” or build by User Defined. Notice: Any question about “User Defined” pleases contact technical support.
  • Page 36 Work Modes Introducation (2) Add existing coordinate system files 1. Click ① to add an existing datum system file. 2. Select a datum system file be imported before. Notice:The dam file can be built with HGO post processing software or be output by User Defined.
  • Page 37 The application of NFC, combined with new intelligent handheld, a light touch will realize automatically connecting to receiver and run the software through Bluetooth. Compared to the past complicated connection process, V100 GNSS receiver is more convenient and efficient. 1. Long press "APP" button on keyboard.
  • Page 38 Work Modes Introducation Bluetooth connection The receiver can also be connected by Bluetooth manually. 1. Slip to Device tab. 2. Press Device. 3. Select Bluetooth. 4. Press Connect.
  • Page 39 V100 GNSS RTK System Getting Started 5. Search device. 6. Or select the receiver from the list directly. 7. When connect to a new receiver, PIN is needed. 8. Enter 1234,press OK.
  • Page 40 Work Modes Introducation 4. Rover setting 1. Slip to Device tab. 2. Press Rover. 3. Press ③ to set Data-link. 4. Select Data Collector Internet mode.
  • Page 41 V100 GNSS RTK System Getting Started 5. Make sure your controller has SIM cards installed. Select the right APN option. 6. Press ⑥ to select communication mode. 7. Select CORS.
  • Page 42 Work Modes Introducation 8. Enter the IP &Port value got from the CORS operator. 9. Press Set to get and select mount-points (nodes). 10. Enter the username & password. 11. Tick RTCM1021/RTCM1023 if your CORS service operator provides this type of message. 12.
  • Page 43 V100 GNSS RTK System Getting Started 5. Floating box Figure 3-5 "Solution state": It is mainly divided into the following several modes (except for fixed coordinate, precision is arranged from high level to low level):The given point refers to fixed coordinate (Base) → RTK fixed solution →...
  • Page 44 Work Modes Introducation Click the satellite icon in the floating window to rapidly check detailed information of current connected receiver satellite. (1) Position information Figure 3-6 Press here to display position information of current point, including position, speed, solution state and time, etc...
  • Page 45 V100 GNSS RTK System Getting Started ◇Distribution situation of projection position of satellite can be viewed by pressing here. Roundness refers to GPS satellite and SBAS satellite, square refers to GLONASS and BDS satellite. GPS: Prn value is 1-32; GLONASS: Prn value is 65-96; BDS: Prn value is 161-197.

  • Page 46: Data Collection

    Work Modes Introducation (3) Signal-to-noise ratio figure of satellite: Prn refers to number of satellite; Azi refers to azimuth angle of satellite; Ele refers to satellite elevation, L1 refers to signal to noise ratio of L1, and L2 refers to signal to noise ratio of L2. ◇Click "SAT Info", and Prn refers to number of satellite, L1 refers to signal to noise ratio of L1, L2 refers...
  • Page 47 V100 GNSS RTK System Getting Started 1. Slip to Survey tab.Press Detail Survey. 2. Press ② to expand the list. 1. Single-point collection Single-point collection means collecting the data of each point by manual operation.
  • Page 48 Work Modes Introducation 1. Press ① (or the same button on physical keyboard) to collect. 2. Press ② to select the height type then input the value. The information of point, including point name, target height (the first point needs to be measured and this value will be set as the default to the next points) and point position description (non-input optional).Click "OK"...
  • Page 49 V100 GNSS RTK System Getting Started 2. Average collection That is averaging for the multi-measurement value of coordinate for each point. 1. Press ① to collect. 2. Press OK to save the point. 3. Press here to change the configuration.
  • Page 50 Work Modes Introducation 3. Automatic collection Point measurement will be recorded automatically according to the configured record condition. 1. Press ① to start automatic collection. 2. Select the mode and enter the interval. 3. Press OK to start collecting.
  • Page 51 V100 GNSS RTK System Getting Started 4. All the points will be auto saved. Press here to end collecting. 4. View all collected points 1. Press ① to view all collected points. Press ② to manage the raw data.

  • Page 52: Stake Out

    Work Modes Introducation All the collected points will be displayed in this interface. 3.2.3. Stake ou 1. Import the stake point 1) Add the point manually 1. Press ① to add the point manually.
  • Page 53 V100 GNSS RTK System Getting Started 2. Press ② to add point to the list. You can add stake point by: ③Enter manually ④Get from receiver ⑤Select from list ⑥Map picking Press OK to confirm. 2) Import the points/lines from file...
  • Page 54 Work Modes Introducation 1. Press ① to import the points from file. 2. Slip to Stake Point. 3. Select Import. 4. Choose the file you uploaded.
  • Page 55 V100 GNSS RTK System Getting Started 2. Point Staking 1. Slip to Survey tab. 2. Press Stake Points. 3. Click here to enter into points selection interface.
  • Page 56 Work Modes Introducation You can add stake point by: ④Enter the point name then search it from list ⑤Input the coordinates manually and save the point to the list by ticking the option ⑥Select from list ⑦Map picking Press OK to confirm and start staking-out.
  • Page 57 V100 GNSS RTK System Getting Started 3. Line staking 1. Stake line from line library. 1. Press Stake Line. 2. Press ② to expand the list. 3. Press ③ to add the line from library. Notice：You can define the line to be staked-out manually or import it from files. Please refer...

  • Page 58: Data Export

    Work Modes Introducation 3.2.4. Data exportt Data achievement export supports the following format: *.txt, *.CSV, *.dxf, (shp File)*.shp and (Excel File)*.csv. 1. Press Data Transfer. 2. Press ② to select data type. 3. Press ③ to select exchange type. 4. Choose the path to output. 5.

  • Page 59: Auto-Backup And Quickly Recover

    V100 GNSS RTK System Getting Started 3.2.5. Auto-backup and quickly recover Project is auto restored in Hi-Survey. External SD card is used for important data backup (Including: Raw data, project file, coordinate system or encryption code file). 1. Press Project Info.
  • Page 60 Work Modes Introducation 3. Turn on the Auto backup option. 4. Select the project to be recovered from the list. 5. Press Start Recovery. Notice： The path of backup file: External SD card /ZHD-Bak/Project/Road. Notice： 1. External SD card is necessary for this function. 2.

  • Page 61: Base Mode With External Radio

    V100 GNSS RTK System Getting Started 3.3. Base mode with external radio When connected with an external radio,V100 GNSS receiver can also work as a GNSS base. 1. Connect to V100 GNSS receiver then press Base. 2. Select the height type and input the Target Height.
  • Page 62 7. Select the correction message type. 8. Set the Elevation angle. Press Set to confirm. Notice： For the details of Radio which is supported and how to configure the connection, please refer to the related documents on Hi-Target website： www.hi-target.com.cn...

  • Page 63: Trouble Shooting

    V100 GNSS RTK System Getting Started C C H A P T E E R Trouble Shooting ■ Registration procedure ■ Firmware upgrade ■ Reset operation ■ Schedule1 factory default parameters ■ Schedule2 key accessories information...

  • Page 64: Registration Procedure

    Trouble Shooting 4.1. Registration procedure Register iHand20 Step 1: Run the Auth Code App which icon is like a lock. (You can find it on the desktop or the Apps Listing.) Step 2: Enter the registration code in the input box, then click submit. Figure 4-1-1...
  • Page 65 V100 GNSS RTK System Getting Started Register GNSS receiver via Hi-Survey App Step 3: Power on your GNSS receiver then run the Hi-Survey App and click the Device icon. Step 4: Connect your GNSS receiver first, and then click the Register icon.

  • Page 66: Firmware Upgrade

    It will appear “UPDATE” disk after being connected, then open the disk, copy the firmware files to it. Remove it and disconnect USB cable, restart GNSS receiver. The receiver will upgrade the firmware automatically. The new firmware can be downloaded from: www.hi-target.com.cn Figure 4-2-1...

  • Page 67: Reset Operation

    V100 GNSS RTK System Getting Started 4.3. Reset operation When the Bluetooth is not connected, satellite searching fails and network connection fails, the operation can be conducted in case that instrument restarting does not work. Reset receiver: In power on status, long press power button (>6s) when LED begins flashing, release...

  • Page 68: Schedule1 Factory Default Parameters

    Schedule2 key accessories information Table 3 key accessories information Name Version Manufacturer Main performance index Motherboard BD970 Trimble 220channels Small measuring 51dB Hi-Target Surveying zero phase Antenna Instrument Co., Ltd antenna ZHD20150010B Hi-Target Surveying Databoard [PCBA] Instrument Co., Ltd...
