SPECIFICATIONS

SPECIFICATIONS*
Pipe Sizes
Fittings
Pressure
Temperature Operating
Non-Operating
Accuracy
Materials Body (3" Only)
Body (4"-12")
Liner (3" Only)
Liner (4"-12")
Electronics Housing
Electrodes
O-ring (3" Only)
Display
Digits
Units
Power
Pulse Output Signal
Pulse Rates
High Frequency
(pulse/gal)
Conductivity
Empty Pipe Detection
Environmental
Regulatory
*Specifications subject to change. Please consult our website for the most current data (www.seametrics.com).
FLOW RANGE (3" - 12")
Meter 3"
Size
Gal/Min Liter/Sec
Minimum
7.5 .47
Maximum
700 44.2
3",4", 6", 8", 10", 12"
ANSI 150 lb. drilling
150 psi (10.3 bar) working pressure
10˚ to 130˚ F (-12˚ to 54˚ C)
-40˚ to 158˚ F (-40˚ to 70˚ C)
+/- 1% of reading for flow between 10% to 100% of max flow
+/- 2% of reading for flow from cutoff to 10% of max flow
Ductile cast iron, powder coated
Welded steel, epoxy-coated
Noryl®
Santoprene/Polypropylene
Diecast aluminum, powder-coated (non-IP68)
316 stainless steel
EPDM
Rate
5
Gallon/Minute, Liter/Minute, Liter/Second,
Cubic Feet/Minute, Cubic Meter/Hour,
Million Gallon/Day, Mega Liter/Day
WMX101: 8-32 Vdc at 30 mA max, with auxiliary battery for continuous operation during power failures
NOTE: Using an unregulated power supply >18 Vdc may damage the meter due to AC line input voltage fluctuation
WMX104: 2 Lithium 3.6V "D" batteries, replaceable, 1 year life under continuous use.
WMX101: Current sinking pulse, opto-isolated, 30 Vdc at 10 mA max
WMX104: Pulse output available only with addition of post-factory output cable
High Frequency; 10 units/pulse; 100 units/pulse; 1000 units/pulse
3" 4"
16.362
25.228
>20 microSiemens/cm
Hardware/software, conductivity-based
NEMA 4X Standard (IP68 Option)
NSF-61 (3" ONLY)
4" 6"
Gal/Min Liter/Sec Gal/Min Liter/Sec
12 .75 32
1,000 63 2,400
Ductile Cast Iron (IP68)
Total
8
Gallon, Gallon x 1000, Liter, Liter x 1000, Mega Liter,
Cubic Meters, Cubic Meter x 1000, Cubic Feet,
Cubic Feet x 1000
6" 8" 10"
6.307 3.344 2.150
8"
Gal/Min Liter/Sec
2 60 3.8
151.4 4,400 277.6
12"
1.530
10" 12"
Gal/Min Liter/Sec Gal/Min Liter/Sec
95 6 130
7,000 441.6 10,000
8.2
630.9
