Components
2 inch
Meter and Indicator
End Connections
Step 1
Position gasket
at either end
NOTE: Above installation instructions are for WMP101/104-200 (2") and WMP101/104-300 (3") only.
The WMP101/104-100 (1") is provided with integrated NPT female threaded ends.
253.872.0284
3 inch
Step 2
Place adapter
against gasket,
open screw clamps
to clear flanges
1 inch
WMP-Series
Quick Start Guide
Fitting Kit
(2" and 3" models only)
Power/Output Cable
(WMP101 only)
Step 3
Place screw-clamps
over both adapter
and meter flanges
and tighten screws
seametrics.com
