TROUBLESHOOTING

Problem
Blank Display
Flow rate steadily reads
zero when there is flow
Flow rate intermittently
drops when there is flow
Jumpy reading
Meter reads, but no
pulse output (WMX101)
Output pulses missing
S eame tric s • 1 9 0 26 7 2 n d Avenue South • K ent, Washi ngton 98032 • US A
( P) 2 5 3 .87 2 .0 2 8 4 • (F) 2 5 3 . 8 72. 0285 • 1.800. 975. 8153 • www .seametr i cs. com
Probable Cause
Dead battery (WMX104)
No power plus dead battery (WMX101)
Flow is below cutoff (very low)
Pipe is not full
Meter is installed backwards
(display reads [ - ] )
Power connections reversed (WMX101)
Fluid conductivity <20microSiemens/cm
Pipe is not full
Missing or incorrect ground wire
Pulsing flow
Rapidly changing conductivity
(in chemical injection applications)
External device needs pull-up resistor
Reversed leads (polarity sensitive)
Meter not reading
Try...
Replace battery pack
Replace battery pack, check power
connections
Reading will resume when flow increases
Reposition meter for full pipe (see page 4)
Note flow direction arrow, reverse meter
Change power connections
Select another flow meter
Reposition meter for full pipe (see page 4)
Check for proper ground
Use external power source
(allows more flow averaging)
Install chemical injection line downstream
of meter (or far enough upstream to allow
complete mixing of fluids before meter)
Add pull-up resistor
(For details, refer to 'Connecting to PLCs'
Technical Bulletin at www.seametrics.com)
Change output connections
Check display
LT-65200289r1.2 20161020
10/20/16
