Pitco SOLSTICE I12 Quick Reference Card

SOLSTICE I12 COMPUTER QUICK PROGRAMMING CARD

TURN ON and OFF

To Turn the Appliance ON :
Press Button , Display will show:
[HEATING], [MELTING] or [READY].
To Turn the Appliance OFF
Press and Hold Button
The Software number and then [OFF] [OFF]
on single vat or a dual vat if both sides are off.
Note 1: Use Left [I/O] key for left side and Right [I/O] key for the right of dual vat control. Use either key on the single vat controller.

OPERATIONS

To Check Actual Temp : Press
To Check Set Temp : Press
To Check Cook, Shake and Hold Time : Press
Typical displays using key 4 as an example:
Key 4 set for 3 minutes and 28 seconds cook time.
Key 4 Shake Time is set for 2 minutes and :00 seconds before the end of the Cook.
Key 4 Hold Time in set for 10:00 minutes.
In a few moments, the display will return to [READY] or last mode of operation.
To Check Time Remaining on a Non-Displayed Product Key when Multiple Timers are in Use :
Press then the Product Key of the Non – Displaying timer key, The display will switch from showing the lowest
time remaining over to the time remaining for the key that was pressed. Repeat for other keys.
To Start a Cook : When display shows [READY] Press any [L,1,2,3,4,5,6,7,8,9,0,R] Product Key to start cook timer.
The indicator light above will flash to indicate the timer is running:
To End a Cook : When the audible alarm is beeping, press the appropriate Product Key
flashing indicator light, all other indicator lights are off until the key is pressed.
To Cancel a Cook : Press and Hold the Product Key you want to cancel until its indicator light is turned off.
Boil Out Mode : After filling empty vat with water, turn appliance on.
Automatic Entry : When the water temperature reaches just below 212
computer will display.
display then shows
Manual Entry : Press
for Celsius display unit. When last digit is entered, boil mode will start automatically. On
Dual Vat computers both sides will enter boil mode. You must turn off both sides of the
fryer to exit Boil mode.
Solstice I12 Computer, Single Vat (60126801) and Dual Vat (60126802)
12 Product
Keys
(See Note 1)
: (See Note 1)
, Display will show:
, Display shows actual temp and then returns to normal mode.
, Display shows set temp and then returns to normal mode.
, press Product Key
.
then enter Product Key [2] [1] [2] for Fahrenheit or [1] [0] [0]
L20-079 Rev 3 2/07
12 Product On/Off Program
Key Indicators Key Key
L 1 2 3 4
then the Product Key desired. See example below
o
F (100
to continue heating,
Quick Reference Card
Thermometer Clock On/Off
Key Key Key
5 6 7 8
Heat Demand
Indicators
4
with the
(i.e. Key 4)
o
C) the
2
1
9 0 R
1 2
0 0
