SOLSTICE Gas (SG) Series w/Options
SG14, 14R, 14T, 18 Fryer
SG14R
w/ optional
SSTC
SG14
w/ standard
Millivolt T-Stat
STANDARD FRYER FEATURES & ACCESSORIES

Tank - stainless steel construction

Cabinet - stainless front, door and sides

Solstice Burner Technology,

Patented Self Cleaning Burner & Down Draft
Protection
(with upgraded controls, SSTC, Digital,
Computer)

Millivolt Thermostat (T-Stat)

High Temperature safety limit switch

Heavy duty 3/16" bottom door hinge

1 ¼" (3.2 cm) Full port drain valve for fast draining

Separate Manual gas shutoffs, for front servicing

Integrated flue deflector

9"(22.9cm) adjustable legs, easier access to clean

Tube rack, allows crumbs & debris into cool zone

Removable basket hanger, requires no tools

Drain Line Clean out rod

Drain extension

Fryer cleaner sample packet

Choice of basket options :

2-Twin Baskets

1-Full Basket
(not available on 14T or Basket Lifts)
Pitco Frialator, Inc  P.O. Box 501, Concord
SG14T SG18
w/ optional w/ optional
Digital Control I12 computer &
front / rear casters
No blower or ceramics
603-225-6684  FAX: 603-225-8497 
L10-294 Rev 1 04/12
Project_________________________
Item No._________________________
Quantity_________________________
APPLICATION
For High Production Gas frying specify Pitco Solstice Gas
Models SG14, 14R, 14T or SG18 tube fryers with the
patented Solstice Burner Technology. The dependable
blower free atmospheric heating system provides fast
recovery to cook a variety of food products. The Solstice
gas fryer comes standard with a millivolt thermostat, for
melt cycle and boil mode choose the optional quick
responding solid state thermostat with the matchless
ignition system. The optional digital control and the elastic
time computer are available and can be used with our
optional labor saving highly reliable basket lift system. The
patented self cleaning burner and down draft protection
keeps your fryer tuned up for peak daily performance.
MODELS AVAILABLE

SG14
(40-50 lbs, 14 x14" fry area, 110 Kbtu/hr)

SG14R
(40-50 lbs, 14 x14" fry area, 122 Kbtu/hr)

SG14T
(20-25 lbs, 7x 14", 50 Kbtu/hr per side for
this twin tank fryer, 100 Kbtu/hr total

SG18
(70-90 lbs, 18 x 18" fry area, 140Kbtu/hr)
OPTIONS & ACCESSORIES

Matchless Ignition with DVI drain valve interlock
(included with Solid State T-Stat, Digital Control & Computer only)

Solid State T-Stat (SSTC) (

Digital Controller (
2 timers w/melt cycle)

Intellifry I-12 Computer

Backup thermostat
(only on Digital and I-12 computer)

Basket Lift
(must be ordered with Digital Control or Computer)
(To meet AGA/CGA/CSA specification, must be ordered with casters &
installed with flexible gas hose w/ restraining cable)

Stainless Steel back
(not available with basket lift)

9" (22.9 cm) adjustable, non-locking rear & front locking
casters

Flexible gas hose with disconnect and restraining cable

Tank cover

3-Triple Baskets
(not available on 14T or Basket Lifts)

Splash Guard reversible (L/R)

Work shelves call factory for specifications and availabilty.

Fish Grids
(not available on 14T)

Institutional Prison security package

BNB Dump Station, see BNB spec sheet for details L10-199

Filter Options

Filter Drawer system see spec sheet L10-134

SoloFilter system see spec sheet L10-152

SPINFRESH see Spec Sheet L10-524 for details
,
NH 03302-0501  509 Route 3A, Bow, NH 03304
www.pitco.com
Printed in the USA
)
(AT ADDITIONAL COST)
w/melt cycle & boil out mode)
(12 elastic timers w/melt cycle & boil out)
  
6" 8" 12"

18"
