- Page 1 BLIZZARD ® P O W E R P L O W YEARS 1999 2003 www.blizzardplows.com 2003 Assembly & Operation Manual Blizzard ® Power Plow ® Snowplow Model 8611...
-
Page 2: Table Of Contents
Electrical Assembly - Vehicle Harness moval products anywhere else! Testing The Snowplow Power Hitch™ Instruction Your Blizzard Power Plow snowplow is Notes equipped with versatile features design- ed for years of dependable service. The Plow Maintenance... -
Page 3: Snowplow Accessories
All of the accessories pictured below are currently offered for your snow- See page 25 for additional Power plow. See your local authorized Blizzard dealer for pricing and availability. Plow snowplow accessories. Visit our web site at www.blizzardplows.com to view new snowplow accessories and our latest Blizzard snowplow wearables. -
Page 4: Warning
Calumet, MI 49913 The Blizzard Power Plow snowplow is protected by U.S. Patents 5,899,007; 5,638,618 and 6,276,076 B1. Other patents pending. BLZ 1005 Should the WARNING! label or any of the labels... -
Page 5: Snowplow Operation
Snowplow Operation Your Blizzard Power Plow snowplow is the most advanced and versatile A. Compact Position (8'- 6" Blade Width) snowplow on the market. The easy to use controls allow you to automat- • Primary position when transporting ically adjust the plow blade and wings into an infinite number of plowing the snowplow positions. -
Page 6: Assembly Instructions Unpacking & Inspection
Assembly Instructions Unpacking & Inspection Your Blizzard Power Plow snowplow has been packaged to withstand Date of Purchase transit and weather related damage. Fully inspect all components upon receipt of your plow. In the event of shipping damage or missing parts, immediately contact our Customer Service Department at 1-888-680-8600. -
Page 7: Moldboard & A-Frame Assembly
Moldboard & A-Frame Assembly 1. Begin the moldboard assembly by first removing each dust cap from both of the SLIDE BOX CYLINDERS located at the center/rear of the MOLDBOARD. Attach one 7/16"-20 x 9/16"-18 MALE O.R.B. CON- NECTOR to each of the retract ports (#7 & #10) and one 9/16"-18 x 9/16"-18 MALE O.R.B. - Page 8 A-frame. Secure the cylinder to the pivot beam with one 3/4" x 5" 9/16" CLEVIS PIN and one 1/4" x 1-1/2" cotter pin. Extend each cylinder rod until the cylinder base mounting hole aligns with the hole on the A-frame angle cylinder bracket. At this point, insert another clevis pin and secure it with a cotter pin.
- Page 9 Position the plates on either side of the lift/lower cylinder rod and insert the pin through the plates and cylinder rod. With the cylinder connected to the inner draw latch plates, rotate the draw latch assembly toward the draw latch mount holes on the A-frame. Align the holes in the outer draw latch plate with those of the inner draw latch plates and the A-frame.
- Page 10 10. Next, align the mount holes in the pump with the holes in the hinged bracket, located on the A-frame. Note: To help facilitate the pump mount, first angle the hinged bracket as needed and tighten the bracket hardware, locking it in place. CAUTION: When installing the manifold between the mount brackets on the A-frame, hold the manifold at the sides of the block.
- Page 11 12. Next, secure the manifold to the A-frame. Remove both 3/8" flat washers, 3/8" split lock washers and 3/8"-16 x 1-1/4" hex head cap screws from the manifold and align the mount holes with the A-frame brackets. Position the DIODE PACK MOUNT BRACKET against the outside of the A-frame bracket on the driver’s side.
-
Page 12: Electrical Assembly - Plow Harness
Electrical Assembly - Plow Harness Draw Latch Toggle Switch 1. Begin the electrical assembly by connecting the RED POWER WIRE Mount Bracket from the PLOW ELECTRICAL HARNESS to the PUMP motor terminal stud using the hardware provided on the pump. 2. -
Page 13: Electrical Assembly - Vehicle Harness
Electrical Assembly - Vehicle Harness CAUTION: Always perform the vehicle wire harness assem- bly with the vehicle off and the keys out of the ignition. Use caution when testing the electrical wires for the vehicle’s headlight functions. 1. Begin the installation of the electrical harness under the hood. Insert the WHITE POWER CONNECTOR &... - Page 14 8. Connect the vehicle headlights to the main lighting harness using a HEADLIGHT ADAPTER KIT. Due to differences in the construction of the adapter kits, and the various make and model vehicles Blizzard snowplows are installed on, a headlight adapter kit is not packaged with your snowplow.
- Page 15 Pull out and twist each handle to temporarily unlock the pins. Place the light tower into the pockets and relock the pins. See your local Blizzard dealer for com- plete installation instructions for your vehicle undercarriage.
-
Page 16: Testing The Snowplow
Testing The Snowplow 1. Fill the HYDRAULIC PUMP FLUID RESERVOIR with BLIZZARD SNOWPLOW RAPID ACTION HYDRAULIC OIL (P/N 63070) until it is approximately 3/4" from the top of the tank. Replace the cap on the reservoir. Proceed to remove the weather caps from each of the plow and vehicle wire harnesses and connect the plugs. - Page 17 Congratulations on a successful assembly and installation! Once all of the blade and electrical functions have been tested your Blizzard Power Plow snowplow is ready for action. Should you need additional support during a plow assembly or undercarriage installation, contact your local authorized Blizzard dealer.
-
Page 18: Power Hitch™ Instruction
Behind Undercarriage Push Beam BLZ 1023 Should the Mounting & Dismounting Instructions label or any of the labels that came with your snowplow become hard to read or wear off, contact your local authorized Blizzard dealer for replacements. Power Hitch™ Instruction... -
Page 19: Notes
Notes Notes... - Page 20 Maintenance Schedule Maintenance Performed Date Your Blizzard Power Plow snowplow has been designed for years of rugged, dependable service with low maintenance. To ensure proper working condition, follow the maintenance guidelines below and on the next page. CAUTION: Always follow the maintenance guidelines in a timely fashion.
-
Page 21: Storing Your Snowplow
A NLGI Grade 2 multipurpose lithium complex grease with molybdenum (MPGM) is recommended for lubrication. 6. Clean and cover deep scratches or exposed metal with Blizzard Snow- plow white (P/N 61219) or black (P/N 63073) touch-up paint. Contact your local Blizzard dealer for availability. - Page 22 Blizzard Corporation has made an effort to present the above contents accurately, but we do not guarantee its completeness or validity. This information is subject to change at any time, without notice.
-
Page 23: Plow Specifications
All specifications are for the Model 8611 Blizzard Power Plow snowplow. Weight ................23.1 lb. Blizzard Corporation reserves the right, under its Continuous Improvement Policy, to change Mount........A-frame Install w/Hex Head Screws construction or design details and furnish equipment when so altered without reference to Maximum Flow Capacity ..........3.0 gpm... - Page 24 M O D E L 8 6 1 1 PA R T S L I S T Ref. Part Qty. Part Description Number Moldboard & Wing Assembly Parts 52122 Moldboard Weldment Note: The reference numbers listed 61086 Label, WARNING! (BLZ 1005) identify parts shown in the illustration 61082 Decal, Center Moldboard (BLZ 1000)
- Page 25 M O D E L 8 6 1 1 PA R T S L I S T Ref. Part Qty. Part Description Number Pivot Beam & A-frame Assembly Parts (Continued) 40124 Pin, Clevis, 3/4" DIA. x 6" YZ 60273 Hydraulic Hose (Port #3), Straight/45˚, 3/8" x 17" - Plow Raise/Lower, Extend (Base End) 60272 Hydraulic Adapter, 9/16"-18 x 9/16"-18 45˚...
- Page 26 M O D E L 8 6 1 1 PA R T S L I S T Ref. Part Qty. Part Description Number Hydraulic Pump & Manifold Assembly Parts (Continued) 62045 Connector, Electric, Male, Plastic 62096 Seal, Cable, Silicone, Orange (18 AWG) 62116 Cavity Plug, Silicone, White (18-16 AWG) 62097...
- Page 27 Paint provided in 12 oz. spray cans. Blizzard hydraulic oil maintains its viscosity to temperatures as low as -60˚F. Blizzard oil is available by the quart, gallon or case. Parts List (4 of 4)
- Page 28 Blizzard Corporation does not warranty non-Blizzard snowplow service parts or accessories or damage resulting from the use of these unauthorized items. The Blizzard Power Plow is protected by U.S. Patents 5,638,618; 5,899,007; 6,178,669; 6,276,076 and 6,393,737. Other patents pending. 134A...
- Page 29 144A 113A - SEE DETAIL ON PAGE 28. 136A 101A 71 72...
-
Page 30: Hydraulic Manifold Detail
Diagram - Hydraulic Manifold Detail... - Page 31 CONNECTS TO M5 SEE SCHEMATIC ON PAGE 31. MODEL 8611 COIL HARNESS WIRE SCHEMATIC LEFT SLIDE BOX RIGHT ANGLE LEFT ANGLE RIGHT SLIDE BOX LIFT CYL. RAISE LOWER 3000 PSI RV 3 RV 2 2650 PSI 2650 PSI 2800 PSI 2800 PSI CV 3 CV 4...
-
Page 32: Plow Harness
Diagram - Plow Harness... -
Page 33: Plow Harness Wire Schematic
Plow Harness Wire Schematic... - Page 34 Diagram - Main Lighting Harness...
- Page 35 Main Lighting Harness Wire Schematic...
-
Page 36: Vehicle Harness
Diagram - Vehicle Harness... -
Page 37: Vehicle Harness Wire Schematic
Vehicle Harness Wire Schematic... -
Page 38: Molded Plug Pin Locations
WIRE STRIPE BLIZZARD HARNESS PLUG (VEHICLE) COLOR COLOR UNIVERSAL 14 + 2 MOLD (BLUE) (BLACK) COLOR FUNCTION PIN NUMBER WIRE STRIPE BLACK GROUND COLOR COLOR BLACK GROUND BLUE/WHITE (RED) (WHITE) 12 VOLT DC (+) BROWN/WHITE PUMP SOLENOID TO RING BROWN... - Page 39 If the problem is not resolved, replace the harness until the solenoid can be tested or solenoid. a Blizzard dealer can diagnose the problem. Short in the joystick control or wire harness. Disconnect the joystick in the cab. If the pump turns off, there is a short in the electrical system.
- Page 40 Problem Probable Cause(s) Suggested Remedy Plow will not lift. Pump works properly. Coils on the manifold may be damaged. Remove the S6 coil from the cartridge valve. Position a (Continued from page 37.) screwdriver inside of the coil and push the draw latch connect/disconnect toggle switch upward.
- Page 41 Problem Probable Cause(s) Suggested Remedy Plow drops sporadically. Variable flow control valve is opened too far. Turn clockwise 1/16 of a turn and test. NOTE: Never make adjustments when the plow is in the raised position! Fluid pressure will make the valve difficult to adjust and serious injury or death can occur from a falling plow.
-
Page 42: Airpark Boulevard
1. Expendable parts such as cutting edges, plow shoes, hoses, fasteners, blade guides, paint finish, etc. 2. Any snowplow or part thereof which has been repaired or altered by anyone other than an Authorized Blizzard Dealer. 3. Any snowplow or part thereof which has been subject to neglect, misuse, accident, improper installation, maintenance, or storage. -
Page 43: Commercial Warranty
1. Expendable parts such as cutting edges, plow shoes, hoses, fasteners, blade guides, paint finish, etc. 2. Any snowplow or part thereof which has been repaired or altered by anyone other than an Authorized Blizzard Dealer. 3. Any snowplow or part thereof which has been subject to neglect, misuse, accident, improper installation, maintenance, or storage. - Page 44 Loctite Corporation, USA. Velcro is a registered trademark of Velcro Industries B.V. All other trademarks and registered trademarks are the property of their respective owners. All Blizzard snowplows are protected by one or more of [906] 482-5445 Fax the following United States Patents: 5,638,618;...
