Blizzard, PO Box 245038, Milwaukee, WI 53224-9538 • www.blizzardplows.com
UNDERCARRIAGE KIT
GM K2500/2500HD/3500/3600 Silv/Sierra 2011 - __
GM C3500/3600 Silv/Sierra
69982
Installation Instructions
CAUTION
Read this document before installing the
snowplow.
CAUTION
See your BLIZZARD
®
outlet/Web site for
specifi c vehicle application recommendations
before installation. The Undercarriage
Selection Guide has specifi c vehicle and
snowplow requirements.
A DIVISION OF DOUGLAS DYNAMICS, L.L.C.
January 1, 2012
Lit. No. 41606, Rev. 01
2011 - __
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blizzard 69982
Summary of Contents for Blizzard 69982
- Page 1 Blizzard, PO Box 245038, Milwaukee, WI 53224-9538 • www.blizzardplows.com January 1, 2012 Lit. No. 41606, Rev. 01 69982 UNDERCARRIAGE KIT GM K2500/2500HD/3500/3600 Silv/Sierra 2011 - __ GM C3500/3600 Silv/Sierra 2011 - __ Installation Instructions CAUTION Read this document before installing the snowplow.
-
Page 2: Safety Definitions
SAFETY SAFETY DEFINITIONS WARNING/CAUTION & INSTRUCTION LABELS WARNING Become familiar with and inform users about the Indicates a potentially hazardous situation warning and instruction labels on the back of the that, if not avoided, could result in death or blade. serious personal injury. -
Page 3: Safety Precautions
SAFETY SAFETY PRECAUTIONS PERSONAL SAFETY Improper installation and operation could cause • Remove the ignition key and put the vehicle in personal injury and/or equipment and property damage. park or in gear to prevent others from starting the Read and understand labels and the Owner's Manual vehicle during installation or service. -
Page 4: Torque Chart
TORQUE CHART NOISE TORQUE CHART Airborne noise emission during use is below 70 dB(A) CAUTION for the snowplow operator. Read instructions before assembling. Fasteners should be fi nger tight until VIBRATION instructed to tighten according to the torque chart. Use standard methods and practices Operating snowplow vibration does not exceed when attaching snowplow including proper 2.5 m/s... -
Page 5: Installation Instructions
UNDERCARRIAGE INSTALLATION INSTALLATION INSTRUCTIONS 4. Insert a 1/2" x 1-3/4" cap screw and washer through the rectangular opening in the inner surface of the frame, through the frame and the NOTE: For easier assembly and installation, rear bracket. Secure loosely with a 1/2" locknut. vehicle and all snowplow components should Adjust the position of the rear brackets upwards as be on a smooth, level, hard surface, such as... - Page 6 UNDERCARRIAGE INSTALLATION Insert two cap screws with handles and washers CAUTION through the rectangular opening in the rear Use caution not to pinch, cut or drill through bracket and through the previously drilled holes in any wires or hoses running along the frame rail. the vehicle frame.
-
Page 7: Electrical Installation
MOUNT ADAPTER INSTALLATION ELECTRICAL INSTALLATION MOUNT ADAPTER INSTALLATION If the vehicle is equipped with fused battery studs, the If adapter plates are required, install as follows: plow battery cables should not be attached to the fused side (see below). 1. Position an adapter plate against the driver's side portion of the mount adapter as shown. - Page 8 Blizzard or the vehicle manufacturer may require or recommend optional equipment for snow removal. Do not exceed vehicle ratings with a snowplow. Blizzard offers a limited warranty for all snowplows and accessories.
