Kurz-Betriebsanleitung PSQ-AMS
Short Operating Instructions PSQ-AMS
Inhaltsverzeichnis / Table of contents
1.
Sicherheit / Safety
2.
Betriebsbedingungen / Operating conditions
3.
Handbetätigung / Manual operation
4.
Armaturenanbau / Valve mounting
5.
Elektroanschluss / Electric supply
6.
Einstellung der Endlage / Setting of mechanical stop
7.
Inbetriebnahme / Commissioning
Version 2019/03/26
Ausführliche Betriebsanleitung auf Anforderung!
Detailed operating instruction upon request!
Art.Nr.: 8014424
©2019 PS Automation GmbH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSQ 103-AMS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PS Automation PSQ 103-AMS

Summary of Contents for PS Automation PSQ 103-AMS

  • Page 1 Handbetätigung / Manual operation Armaturenanbau / Valve mounting Elektroanschluss / Electric supply Einstellung der Endlage / Setting of mechanical stop Inbetriebnahme / Commissioning Version 2019/03/26 Art.Nr.: 8014424 ©2019 PS Automation GmbH Ausführliche Betriebsanleitung auf Anforderung! Detailed operating instruction upon request!
  • Page 2 Dangerous electrical voltage can be present! Avoid personal or material damages by observing applicable regulations and safety standards! Achtung! Handhabungsvorschriften beachten. Elektrostatisch gefährdete Bauelemente. / Attention! Observe precautions for handling. Electrostatic sensitive devices. 2. Betriebsbedingungen / Operating conditions PSQ 103-AMS: X = 161 mm PSQ 203-AMS: X = 228 mm PSQ 503/703/1003-AMS:...
  • Page 3 5. Elektroanschluss / Electric supply Vor Arbeitsbeginn Netzspannung trennen! Schaltplan in der Haube! Switch off the mains before starting to work! Wiring diagram in the cover! 6. Einstellung der Endlage / Setting of the mechanical stop Nur bei Lieferung ohne Ventil! / Only when supplied without valve! ...
  • Page 4 (only for cut-offs “by position automatically”). Manual commissioning in case both cut-offs is “by position”. This is done either via software PSCS or via local control box PSC.2, see respective instruction manual (available on request). PS Automation GmbH Gesellschaft für Antriebstechnik Philipp-Krämer-Ring 13 D-67098 Bad Dürkheim...
