LokPilot Standard
P Reliable, Dual Mode DCC / DC decoder with B-EMF function
P Four powered function outputs (+2 logic level outputs for 21MTC version)
P RailComPlus® for automatic Registration at ESU ECoS command station
P For all engines equipped with DC- or coreless motors
53611
Digital Decoder
NMRA 8 pin wire harness
DCC & RailComPlus
MADE IN CHINA
Specification
Operational
NMRA/DCC with 14, 28, 128 speed steps.
modes
2-digit (short) and 4-digit (long) addresses.
Analog DC operation (de-selectable).
Automatic recognition of operational mode and DCC speed step selection.
Supports Lenz® LG 100 braking sections.
Throttle
Runs DC and coreless motors.
0,9 A continuous load. Silent, safe 20,00 kHz pulse width frequency motor regulation.
Motor output overload protection; Back EMF (de-selectable).
4 powered outputs with overload protection.
250mA load per output.
500mA total load of all function outputs.
21MTC connector version has two additional logic outputs.
Shunting speed and momentum key selectable.
Programming
DCC Servicemode & DCC POM (Programming on Main).
Features
RailCom® Feedback system. RailComPlus® automatic Registration.
Interface
dimensions in mm
dimensions
Item - Number
This product is not a toy. Not recommended for children under 14 years of age.
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or
other reproductive harm.
ESU P/N 02714-14649
LokPilot Standard
4AOEGOP*fdgbbh+
NEM652 ( 8 pin )
25,5 x 15,5 x 4,5
1.00 x 0.61 x 0.18
53611
Muncy Pennsylvania 17756
21MTC
25,5 x 15,5 x 4,5
1.00 x 0.61 x 0.18
53614
www.esu.eu
ESU LLC
477 Knopp Drive
USA
ESU GmbH & Co. KG
Edisonallee 29
D - 89231 Neu-Ulm
GERMANY
PluX 12
14,5 x 8,3 x 2,4
0.57 x 0.33 x 0.09
53616
