CV
Name
Description
1
Loco address
Short (2 digit) address of locomotive
2
Start voltage
Minimum speed of the locomotive
3
Acceleration
This value multiplied by 0.25 is the time from stop to maximum speed
4
Deceleration
This value multiplied by 0.25 is the time from maximum speed to stop
5
Maximum speed
Maximum speed of the locomotive
6
Medium speed
Medium speed of locomotive
8
Manufacturer's ID
Manufacturers's ID ESU - Writing value 8 in this CV triggers a reset to
factory default values
17 &
Long address of the loco
Long address of engine ( see full manual online at www.loksound.com)
18
19
Consist Address
Additional address for consist operation. Value 0 or 128 means: consist
address is disabled
1 – 127 consist address active, normal direction
129 – 255 consist address active reverse direction
27
Brake mode
Allowed brake modes
Bit
Function
0
ABC braking, voltage higher on the right hand side
1
ABC braking, voltage higher on the left hand side
2
ZIMO® HLU brakes active
3
Brake on DC, if polarity against driving direction
4
Brake on DC, if polarity like driving direction
7
Loco brakes with constant brake distance, if FS=0
28
RailCom® Configuration
Settings for RailCom®
Bit
Function
0
Channel 1 Address broadcast enabled
1
Data transmission allowed on Channel
7
RailCom® Plus automatic loco recognition active
29
Configuration register
Calculated field. Add up the values you want to activate, then write this
number into CV 29.
Bit
Function
0
Normal direction of travel
Reversed direction of travel
1
14 speed steps DCC
28 or 128 speed steps DCC
2
Disable analog operation
Enable analog operation
3
Disable RailCom®
Enable RailCom®
4
Speed curve through CV 2, 5, 6
Speed curve through CV 67 - 94
5
Short addresses (CV 1) in DCC mode
Long addresses (CV 17 + 18) in DCC mode
31
Index register H
Should be either "0" or "16" for LokSound Decoders
Range
CV
Name
Description
Default
1 - 127
3
32
Index register L
CV 32=0 if accessing CVs 1- 255, CV 31=1,2,3 if accessing CVs 257-511
1 - 255
3
48
Master Sound Select
Selects the prime mover sound (0, 16, 32, 64), the horn (0-15), the bell
(0,64), Brake Squeal Sound (0, 128) - add the numbers up for each selec-
0 - 255
80
tion to get the final value of CV 48. Will vary between sound files. Locate
0 - 255
80
the sound file description on our web site for valid values.
0 - 255
255
0 - 255
88
49
Extended
0
Enable Load control (Back-EMF)
Configuration #1
Disable Load control (Back-EMF)
151
-
1
DC Motor PWM frequency
20kHz motor pulse frequency
40 kHz motor pulse frequency
0-255
0
2
Reserved
3
Reserved
28
4
Automatic DCC speed step detection
Value
Disable DCC speed step detection
Enable DCC speed step detection
1
5
LGB® function button mode
2
Disable LGB® function button mode
4
Enable LGB® function button mode
8
6
Reserved
16
128
7
Reserved
131
Value
1
50
Analogue mode
Selection of allowed analogue modes
2
Bit
Description
128
0
AC Analogue Mode ( Only LokSound V4.0)
12
Disable AC Analog Mode
Enable AC Analog Mode
Value
1
DC Analogue mode
Disable DC Analogue mode
0
Enable DC Analogue Mode
1
61
Random sound «min»
Multiplied by 0.25 it is the time in seconds for the shortest random
0
sound interval. F
2
62
Random sound «max»
Multiplied by 0.25 it is the time in seconds for the longest random sound
0
interval.
4
63
Sound volume «Master»
Master volume for all sounds.
0
8
64
Brake sound threshold
If the actual loco speed step is smaller than or equals the value indicated
«Brake On»
here, the brake sound is triggered.
0
16
65
Brake sound threshold
If the actual loco speed step is smaller than the one indicated here (up to
0
«Brake Off»
255), the brake sound will be switched off again. .
32
66
Forward Trim
Divided by 128 is the factor used to multiply the motor voltage when
16
16
driving forward. The value 0 deactivates the trim.
67-
Speed table
Defines motor voltage for speed steps. The values „in between" will be
94
interpolated.
Range
CV
Name
Description
Default
0 - 4
0
95
Reverse Trim
Divided by 128 is the factor used to multiply the motor voltage when
driving backwards. Value 0 deactivates the trim.
0 - 255
113
Power Fail Bypass
The time that the decoder bridges via the PowerPack after an interrup-
tion of voltage. Unit: A multiple of 0.016384 sec.
124
Extended Configura-
Additional important settings for decoders
tion #2
Bit
Description
1
0 - 255
19
0
Bi-directional bit: Enable driving direction when shifting
0
direction.
Disable driving direction.
0
1
Disable decoder lock with CV 15 / 16
2
Enable decoder lock with CV 15 / 16
2
Disable prime mover startup delay
0
Enable prime mover startup delay
0
3
Disable serial protocol for C-Sinus
0
Enable serial protocol for C-Sinus
4
Adaptive regulation frequency
Constant regulation frequency
0
16
5
Motor safety when blocking.
Motor is not switched off when blocked.
Motor is switched off for a few seconds when blocked to
0
avoid burnout
32
125
Starting voltage Analog
DC
0
64
126
Maximum speed Analog
DC
0
127
Starting voltage AC
(ONLY for LokSound V4.0)
128
0 - 3
3
128
Maximum speed Analog
(ONLY for LokSound V4.0)
AC
Value
134
ABC-Mode „Sensibility"
Threshold, from which asymmentry on ABC shall be recognised.
0
1
0
2
0 - 255
120
0 - 255
200
0 - 192
192
0 - 255
100
0 - 255
25
0 - 255
128
See the full manual online at www.loksound.com
0 - 255
-

Quick Start Guide

Range
Default
0 - 255
128
0 - 255
50
-
24
LokSound Select
Value
1
LokSound V4.0
0
0
2
0
4
0
8
0
16
0
32
0 - 255
30
0 - 255
130
0 - 255
50
Technical Data for LokSound Select and LokSound V4.0 Decoders
0 - 255
150
Operational modes
NMRA/DCC with 14, 28, 128 speed steps.
2-digit (short) and 4-digit (long) addresses.
4 - 32
12
Analog DC operation (de-selectable).
Automatic recognition of operational mode and DCC speed step selection.
Power
Runs all DC and coreless motors.
Silent, safe 31,25 kHz pulse width frequency BEMF
Motor output overload protection
8 pin and 21MTC decoders
1.10A continuous load / 2.00 A peak load
Next18 / Select Micro and V4.0 decoders
0.75A continuous load / 1.00 A peak load
Function outputs
8 pin Select and V4.0 decoders
Up to 6 outputs (6 powered)
21MTC Select and V4.0 decoders
Up to 8 outputs (4 powered, 4 logic)
Next18 / Select Micro and V4.0 decoders
Up to 6 outputs (4 powered, 2 logic)
Sound
Audio amplifier: 2W @ 4 Ohm load
Speaker impedance 4 - 16 Ohms
Memory capacity 32 MBit
8 sound channels, all playable at once!
Over 20 different sounds!
Programming
DCC Servicemode & DCC POM (Programming on Main).
Features
RailCom® Feedback system. RailComPlus® automatic Registration.
