When operating in uplink/downlink mode the transmission and reception will take about 40 to 50 seconds. In this period the
device will first send a data telegram three times as shown in
consumption for about 20s and will then enter the receive mode for about 20s with 19mA current consumption. Finally a
confirm telegram is sent for about 2s. This uplink/downlink mode is only possible for max. 4 transmissions/day and has to be
added to the Mean Current consumptions in
During the uplink/downlink operation the MCU can be placed in power-down mode and can wake-up by the event of the
ATA8520D.
5.2 Connector Description
The PCB has several connectors which are used differently depending on the PCB configuration.
connectors and how different PCB versions are used.
The placement of the connectors at the PCB is shown in
Table 5-2. ATAB0101A Connectors
Connector
X1 ext. power
X2 Xplained Pro
X3 Xplained mini
X4 Xplained mini
X5 Xplained mini
X6 Xplained mini
X7 RF debug
X8 sensor
J1 RF config.
XISP1
XISP2
5.2.1 Connector X1
Connector X1 is used for supplying an external 3V power source for standalone battery powered applications for the
ATA8520-EK1-E kit.
These pins have no reverse polarity protection.
Caution:
Table 5-3. Connector X1
Table
ATA8520-EK1-E
Standalone Version
External 3V power supply
--
--
--
--
--
--
External sensors
PB0/PB1 pin usage
ISP-microcontroller connector
--
Function
+3.3V
Figure 5-2, followed by an idle mode with about 4.5mA current
5-1.
Figure 5-1 on page 9.
ATA8520-EK3-E
Xplained Pro Extension
--
Extension connector
--
--
--
--
--
External sensors
PB0/PB1 pin usage
--
--
Pin Pin
1 2
ATAN0104 [APPLICATION NOTE]
Table 5-2 summarizes the
ATA8520-EK2-E
Xplained Mini Extension
--
--
Shield connector1
Shield connector2
Shield connector3
Shield connector4
--
External sensors
PB0/PB1 pin usage
--
--
Function
GND
11
