Summary of Contents for Atmel ATAVRAUTO102
- Page 1 ATAVRAUTO102 Kit ....................User Guide...
-
Page 2: Table Of Contents
Section 2 Getting Started..................2-3 Unpacking the system................2-3 System Requirements................2-3 Section 3 Using the ATAVRAUTO102..............3-5 Using the ATAVRAUTO102 board............3-5 Updating the ATAVRAUTO102 firmware ..........3-5 Using X-Analyser ..................3-8 Section 4 Technical specification................ 4-11 Section 5 Technical support ................5-12 Section 6 Complete schematics ................. -
Page 3: Introduction
This board is not a development platform but a tool designed to give designers a quick start to analyze LIN and/or CAN networks in order to evaluate Atmel LIN and CAN solutions. Figure 1-1. ATAVRAUTO102 ATAVRAUTO102 User Guide 7720A–AVR–06/07... - Page 4 4.12 or higher. For up-to-date information on this and other AVR tool prod- ucts, please consult our web site. The newest version of AVR Studio, AVR tools and this user guide can be found in the AVR section of the Atmel web site, http://www.atmel.com.
-
Page 5: Getting Started
1 AVR CD-Rom software and technical library 1 Dear customer letter System Requirements The ATAVRAUTO102 board is used as a tool to analyze car networks (up to two LIN net- works and one CAN network). The minimum hardware and software PC requirements are: ®... - Page 6 Quick Start The ATAVRAUTO102 board can be used to analyze up to one CAN and two LIN net- works. Connect networks (LIN and/or CAN) and plug USB cable. Figure 2-1. Board connections and default jumpers settings VBat LIN0 VBat LIN1...
-
Page 7: Using The Atavrauto102
Section 3 Using the ATAVRAUTO102 Using the ATAVRAUTO102 board The ATAVRAUTO102 can be used as a spy on a network or can act as a single Slave or Master node. LIN0 can be sniffer/slave or master. LIN1 can be sniffer or slave. - Page 8 AT90CAN128. Due to the small size, it is also an excellent tool for field Adaptor upgrades of existing applications. It is powered by the ATAVRAUTO102 and an addi- tional power supply is thus not required. The AVR ISP programming interface is integrated in AVR Studio®.
- Page 9 PDI (PE0) and PDO (PE1). To program the device using AVR ISP programmer, connect the AVR ISP to the adaptor (ATAVRAUTO900) and connect the adaptor to the connector of the ATAVRAUTO102. Programming the ATAVRAUTO102 using ATAVRAUTO 900 3.2.3...
- Page 10 ATAnalyser is the only running application, the O.S. allows the application to received USB frames only every 10 ms. A buffer permits to save received USB frames but for very high bitrates, there could be a loss of received USB frames. ATAVRAUTO102 User Guide 7720A–AVR–06/07...
-
Page 11: Technical Specification
Section 4 Technical specification System Unit – Physical Dimensions..........L=92 x W=45 x H=14 mm – Weight......................31 g Operating Conditions – Internal Voltage Supply (Flash)..............3.3V – Internal Voltage Supply (Micro)..............5.0V – External Voltage Supply..............7V -18V ATAVRAUTO102 User Guide 4-11 7720A–AVR–06/07... -
Page 12: Technical Support
Section 5 Technical support For Technical support, please contact avr@Atmel.com. When requesting technical sup- port, please include the following information: Which target AVR device is used (complete part number) Target voltage and speed Clock source and fuse setting of the AVR... -
Page 13: Complete Schematics
Section 6 Complete schematics On the next pages, the following documents of ATAVRAUTO102 are shown: Bill of materials Complete schematics Assembly drawing ATAVRAUTO102 User Guide 6-13 7720A–AVR–06/07... - Page 14 2.17 Res 56R 0603 1% 0603 BC847 BC847 PHILIPS FARNELL 1081230 1.4 BC847 SOT23 BCP54 BCP54-10 PHILIPS FARNELL 8734828 0.63 BCP54 SOT223 SI2301BDS SI2301BDS VISHAY FARNELL 8156670 2.7 SI2301BDS SOT23-GSD ATAVRAUTO102 User Guide 6-14 7720A–AVR–06/07 27/03/2007 Page 1 Altium Limited Confidential...
- Page 15 Complete schematics ATAVRAUTO102 User Guide 6-15 7720A–AVR–06/07...
- Page 16 Complete schematics ATAVRAUTO102 User Guide 6-16 7720A–AVR–06/07...
- Page 17 Complete schematics ATAVRAUTO102 User Guide 6-17 7720A–AVR–06/07...
- Page 18 Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN ATMEL’S TERMS AND CONDI- TIONS OF SALE LOCATED ON ATMEL’S WEB SITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY...
- Page 19 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Microchip ATAVRAUTO102...
