- Page 1 ATAB542x-x-WB User Guide ....................ATMEL “Wireless BlackBird” Transceiver Demonstration Kit...
- Page 2 Introduction ................... 1-1 Purpose.....................1-1 Description ....................1-1 Performance Characteristics..............1-2 Kit Contents....................1-2 Operating the Transceivers ..............2-1 Menu Guide Description................2-1 The Abridged Menu Guide ................2-2 The Exhaustive Menu Guide..............2-3 Appendix....................3-1 Miscellaneous Information ................3-1 3.1.1 Software re-load and FUSE settings ..........3-1 3.1.2 Software documentation ..............3-2 ATAB542x-x-WB User Guide 5219A–WIRE–04/07...
- Page 3 Description The ATMEL Wireless BlackBird is a 2" x 3.5" PC-board transceiver using the ATA542x UHF transceiver IC and the ATmega3290 AVR micro-controller, as shown in Figure 1-1. It is offered in five frequencies: 315, 345, 434, 868, and 915 MHz. The BlackBird is UART-, ISP-, and JTAG- ready.
- Page 4 The ATAB542x kit contains two ATAB542x transceivers (with batteries), as determined by the ATMEL part number ordered, a Quick Start Card, and a CD. The kit is complete, the software is preloaded, and it is ready for immediate use. Figure 1-2 shows the kit contents.
- Page 5 Introduction Figure 1-1. Wireless BlackBird Transceiver Figure 1-2. Wireless BlackBird Demonstration Kit ATAB542x-x-WB User Guide 5219A–WIRE–04/07...
- Page 6 Section 2 Operating the Transceivers This section contains remarks about how the Menu Guides, both abridged and exhaus- tive, are set-up and how to use them. Then, both versions of the Menu Guide, respectively, are given. Menu Guide These menu guides are intended to provide the user with two views of the demo-soft- ware menu.
- Page 7 Operating the Transceivers 5. the letters "X" or "x" are used in this outline to indicate display of a number that has a variable value. The Abridged There are 6 main menus: Menu Guide DIAGNOSTICS LINK QUALITY TEMPERATURE SENSOR LIGHT SENSOR FREQ HOPPER SYSTEM SETUP They are accessible by moving the joystick downward (not to be confused with pressing...
- Page 8 To power-up the transceiver, slide the white-and-black switch downward. The text Menu Guide ATMEL WIRELESS BLACKBIRD scrolls across the screen. The AVR logo and the device part number (542x) are also displayed. At this point: P - displays VERSION X.XX, the current version of the demo software P,L,R,U,D - goes to power-up display (ATMEL SMARTRF...)
- Page 9 Operating the Transceivers radio is transmitting, indicated by AVR logo and antenna icon P,L,R,U,D - goes to START and stops transmitting START - exits or re-starts TX mode P - re-starts TX mode L - goes to MARK (main menu) U,D - goes to EXIT EXIT - exits TX mode P,L - goes to MARK (main menu)
- Page 10 Operating the Transceivers 2.3.1.4 RSSI Indicates received signal strength Note: a 2nd transceiver must be put into one of the above transmit modes (MARK, SPACE, or TOGGLE) in order to see a received signal strength indication P - accesses menu items L - goes to DIAGNOSTICS U,D - scrolls thru menu (MARK, SPACE, ...) CH x - sets radio channel (0 to 9)
- Page 11 Operating the Transceivers L - goes to PKT TX (main menu) U - resets counter to 0000 HOW TO EXECUTE THE “PKT TX” FEATURE: When ready to transmit, the blinking text PKT TX and 0000 is displayed. On the RX, a portion of the data packet (for exam- ple, 0D5500) and a 4-digit number is displayed.
- Page 12 Note: this demonstration requires 2 transceivers P - accesses menu items L - goes to power-up display (ATMEL SMARTRF...) U,D - scrolls through menu (DIAGNOSTICS, LINK QUALITY, ...) CH x - sets radio channel (0 to 9) P - sets channel and goes to FSK...
- Page 13 Note: this demonstration requires 2 transceivers P - accesses menu items L - goes to power-up display (ATMEL SMARTRF...) U,D - scrolls through menu (DIAGNOSTICS, LINK QUALITY, ...) CH x - sets radio channel (0 - 9) P - sets channel and goes to FSK...
- Page 14 SYSTEM SETUP menu, under UNIT ID ADR utility, the REMOTE IDs can be set manually to any value 0 to 255 P - accesses menu items L - goes to power-up display (ATMEL SMARTRF...) U,D - scrolls through menu (DIAGNOSTICS, LINK QUALITY, ...) CH x - sets radio channel (0 - 9)
- Page 15 Operating the Transceivers x KBPS - sets data rate P - sets data rate and goes to *WAIT*, antenna blinking L - goes to *WAIT*, antenna blinking U,D - changes data rate (1,5,10 kbps for ASK; 1,5,10,20 kbps for FSK) *WAIT*, blinking antenna - transceiver is in REMOTE mode Note: All transceivers except ONE (regardless of a single- or multi-sensor demo) should be left as a REMOTE at the *WAIT*, blinking antenna display.
- Page 16 Note: this demonstration requires 2 transceivers P - accesses menu items L - goes to power-up display (ATMEL SMARTRF...) U,D - scrolls through menu (DIAGNOSTICS, LINK QUALITY, ...) *WAIT* - ready to begin demo L - goes to FREQ HOPPER...
- Page 17 U,D - toggles between PWR OFF and PWR SAVE PWR SAVE - display and radio are off; 32kHz oscillator and real-time clock are on P - wakes-up part at power-up display (ATMEL SMARTRF...) PWR OFF - turns display and radio off; uC is asleep; max draw <1uA P - wakes-up part at SYSTEM SETUP 2.3.6.2...
- Page 18 Operating the Transceivers P - sets selected address number and goes to SYSTEM SET-UP L - goes to SYSTEM U,D - changes address to 0 thru 255 2.3.6.4 SET DATE/TIME Sets date and time of internal clock P - accesses menu items L - goes to SYSTEM SET-UP U,D - scrolls through menu (PWR DWN, CHANNEL ADJUST…) MONTH - sets month...
- Page 19 Operating the Transceivers day, date, and time displayed P (again) - goes to SYSTEM 2.3.6.5 PWR LVL Sets power output LO ~ 0dBm, HI ~ 8dBm) P - accesses menu items L - goes to SYSTEM SET-UP U,D - scrolls through menu (PWR DWN, CHANNEL ADJUST…) P LO - sets power output P - sets value and goes to SYSTEM SET-UP U - selects P HI...
- Page 20 Operating the Transceivers L,R,U,D - goes to SYSTEM SETUP P (again) - goes to LGHT 2 VCC 3 - the voltage source output is on A/D channel 3 P - displays the hex value out of the A/D converter L,R,U,D - goes to SYSTEM SET-UP L,R,U,D - goes to SYSTEM SETUP P (again) - goes to VCC 3 2.3.6.8...
- Page 21 Operating the Transceivers U,D - scrolls through menu (5423 – 315MHZ, 5425 – 345MHZ,…) 5428 – 433MHZ - selects pre-set data for 433MHz P - selects 433MHz data is loaded, and then goes to SYSTEM SET-UP L - goes to SYSTEM SET-UP U,D - scrolls through menu (5423 –...
- Page 22 Section 3 Appendix Miscellaneous Information 3.1.1 Software re-load and If at any time the software for the BlackBird needs to be re-loaded, please use the file: FUSE settings CD:\software\IARSRF_B100.hex In addition to programming the BlackBird with the executable software, the FUSEs must be correctly set.
- Page 23 Appendix Figure 3-1. 3.1.2 Software To facilitate understanding the source code, it is recommended that DOXYGEN soft- documentation ware (http://www.doxygen.com) be used to generate documentation. A file called “Doxyfile” is on the CD in the software directory. This file will be helpful when generating documentation with DOXYGEN.
- Page 24 Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN ATMEL’S TERMS AND CONDI- TIONS OF SALE LOCATED ON ATMEL’S WEB SITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY...
