Default settings
AFG2021 Quick Start User Manual
Default settings
Menu/System
Output configuration
Function
Frequency
Amplitude
Offset
Symmetry (ramp)
Duty (Pulse)
Output Units
Output impedance
Output invert
Output noise add
Sweep
Sweep start frequency
Sweep stop frequency
Sweep time
Sweep hold time
Sweep return time
Sweep type
Sweep mode
Sweep source
Trigger slope
Trigger interval
Modulation
Modulation waveform
AM depth
FM deviation
PM deviation
FSK hop frequency
FSK rate
PWM deviation
Burst
Burst mode
Burst count
Trigger source
Trigger delay
Trigger interval
Instrument front panel, interface, and rear panel
Default setting
Sine
1.000 000 000 00 MHz
1.000 Vp-p
0 mV
50.00%
50.00%
Vp-p
50 Ω
Off
Off
100.000 kHz
100.000 MHz
10 ms
0 ms
1 ms
Linear
Repeat
Internal
Positive
1.000 ms
10.00 kHz, Sine (except FSK)
50.00 Hz, Square (FSK)
50.00%
1.000 000 MHz
90.0°
1.000 000 MHz
50.00 Hz
5.00%
N-Cycles
5
Internal
0.0 ns
1.000 ms
