Select a local language

Protect your instrument from misuse

Check input and output
connectors
AFG2021 Quick Start User Manual
You can select the language you want displayed on the instrument screen. When
you power on the instrument for the first time, English is selected by default.
After you select a desired language, all the bezel menus, pop-up messages, and
built-in help are displayed in the specified language. The main display area
is not translated.
1. Push the front-panel Utility
button.
2. Push the Language bezel
button.
3. Select the desired
language.
You can select from
English, French, German,
Japanese, Korean,
Simplified Chinese,
Traditional Chinese, and
Russian.
NOTE. If you selected a language option with the purchase of the instrument, you
should have received a front panel overlay.
When connecting a cable, be sure to distinguish the input connector from the
output connectors to avoid making the wrong connection.
NOTE.
The instrument input and output connectors are floating inputs/outputs.
(See page 11, Floating ground.)
Getting started
9
