Erase instrument setups and waveforms from memory

Perform instrument self test and self calibration

AFG2021 Quick Start User Manual
You can also erase all instrument setups and waveforms from the instrument
internal memory using the following procedure.
NOTE.
You can restore the instrument to its default settings at any time without
erasing memory by using the default setup procedure. (See page 24.)
1. Push the front-panel Utility
button.
2. Push the System bezel
button.
3. Push the Secure bezel
button.
The instrument performs a limited set of hardware tests at power-on. You can
also perform the following manual diagnostics and/or self calibration using the
Utility menu:
NOTE.
Disconnect all the cables from the instrument before performing a self
test or a self calibration.
Diagnostics (Self test): Perform the self test to verify that your instrument
is operating correctly.
Calibration (Self calibration): The self calibration mainly checks DC accuracy
using the internal calibration routines. Perform at least once a year to maintain
