Summary of Contents for Proxim AP-4900MR-LR
- Page 1 Quick Install Guide AP-4900MR-LR Outdoor Access Point Software Version 3.3 Quick Install Part Number 73064 r2 (Print version) Part Number 73065 r2 (CD version)
-
Page 2: Notices
Proxim Wireless Corporation. trademarks ORiNOCO and Proxim are registered trademarks, and the Proxim logo is a trademark, of Proxim Wireless Corporation. All other trademarks mentioned herein are the property of their respective owners. -
Page 3: Table Of Contents
coNteNts Notices................2 Copyright .....................2 Trademarks ..................2 Introduction..............4 Package.Contents............6 Hardware.and.Software.Installation........ 8 Step 1: Choose a Location ..............9 Step 2: Pre-Assemble the Hardware ............10 Step 3: Connect the Cables ..............13 Step 4: Power on the Unit ..............15 Step 5: View LEDs................ -
Page 4: Introduction
Figure You can verify which hardware version you are using through either the HTTP Interface or CLI Interface. See the AP-4900MR-LR User Guide for information on locating your hardware version number. AP-4900MR-LR units can operate either using PoE with the combination DC power supply/injector provided or directly from a 100 - 240 VAC power source (AC cable ordered separately). - Page 5 Figure.1:.AP-4900MR-LR.Unit.(Dual.LEDs.and.Serial.Connection) Figure.2:.AP-4900MR-LR.FC.Unit.(Single.LED.and.No.Serial.Connection) All rights reserved Page 5...
-
Page 6: Package.contents
PackaGe coNteNts Each AP-4900MR-LR shipment includes the items in the following table. Verify that you have received all parts of the shipment. Note: Unless listed here, cables are not included with the unit. AP-4900MR-LR Unit RJ11 to DB9 serial connector (not included... - Page 7 Mounting Kit Kit includes the following: A. Mounting clamp for wall/pole B. Extension arm C. Mounting plate to enclosure D. Mounting clamp for pole mounting Mounting Hardware The following mounting hardware is included with mounting kit: Qty. Description 6 ea Plain washer #5/16 2 ea.
-
Page 8: Hardware.and.software.installation
Information on the product CD for important information. IMPORTANT! IMPORTANT! All AP-4900MR-LR units must be installed by a suitably trained profession- All AP-4900MR-LR units must be installed by a suitably trained profession- al installation technician or by a qualified installation service. -
Page 9: Step 1: Choose A Location
To make optimal use of the unit, you must find a suitable location for the hardware. The range of the radio unit largely depends upon the position of the antenna. Proxim recommends you do a site survey, observing the following requirements, before mounting the hardware. -
Page 10: Step 2: Pre-Assemble The Hardware
Note: The serial number is required to obtain support from Proxim. Keep this information in a safe place. You will be attaching an outdoor-rated 24 AWG CAT5 cable (diameter .114 to .250 inches/2.9 to 6.4 mm) (not provided) to the Power-over-Ethernet... - Page 11 Caution!. The.sealing.nut.(A).must.not.be.tightened.until.the.sealing.cap.(C). over the RJ45 connector has been tightened to the unit during final installation;.otherwise,.the.Ethernet.cable.may.twist.and.become. damaged. Notes:. ▪ The cable must feed through all parts of the weatherproof cap before the RJ45 is crimped on the outdoor Ethernet a cable. ▪...
- Page 12 Attach the mounting bracket (C) to extension arm (B) with the screw, nut, and washers provided. Tighten assembly (Torque 15 N∙m/130 in-lbs). The following figure shows the full assembly attached to the unit: Page 12 Copyright © 2006 Proxim Wireless...
-
Page 13: Step 3: Connect The Cables
step 3: connect the cables If you have not already done so, connect the normal RJ45 connector on an outdoor-rated CAT5 cable to the “Data and Power Out” port on the power injector. Note: On FC versions, connect the cable to the port labeled “J1 Antenna” on the power injector (not pictured). - Page 14 Note: On FC units, connect the cross-over cable between the network interface card in the PC and the and the RJ45 “J2 PC/Router” port on the power injector (not pictured). Page 14 Copyright © 2006 Proxim Wireless...
-
Page 15: Step 4: Power On The Unit
step 4: Power on the unit The power injector provides Power-over-Ethernet (PoE), supplying electricity and wired connectivity to the unit over a single 24 AWG CAT5 (diameter .114 to .250 inches/2.9 to 6.4 mm). The unit is not 802.3af-compatible. Always use the supplied power injector to ensure that the unit is powered properly. -
Page 16: Step 5: View Leds
On power-up, the LED flashes red during initial start-up, and then turns solid red while booting. After a successful boot, it becomes solid green to indicate normal operation. Caution! Before.applying.power.to.the.units,.make.sure.that.a.proper.load.or. antenna.is.connected.to.each.N-female.jack.to.minimize.the.chance. of damaging the internal RF power amplifiers. Page 16 Copyright © 2006 Proxim Wireless... -
Page 17: Step 6: Mount The Unit
Prereq- perform initial configuration of the parameters mentioned in the Prereq- uisites section of this AP-4900MR-LR User Guide before you mount the uisites section of this AP-4900MR-LR User Guide before you mount the AP. -
Page 18: Step 7: Complete Installation
Tighten the sealing nut (Torque 3 N∙m/25 in-lbs) and lock nut (Torque 4 N∙m/35 in-lbs). CAUTION!. Do.not.over-tighten!.Over-tightening.can.cause.the.CAT5.cable.to. become.pinched.and.can.subsequently.damage.the.power.injector. or.the.unit... Tighten the RJ45 sealing cap. CAUTION! Be.sure.you.have.re-installed.the.waterproof.caps.on.the.serial.and. Ethernet.port.connections...It.is.also.good.installation.practice.to. use Butyl weatherproofing tape to seal the caps, as this adds an extra.layer.of.protection. Page 1 Copyright © 2006 Proxim Wireless... -
Page 19: Step 8: Install Documentation And Software
AP-4900MR-LR Antenna Installation Guide – AP-4900MR-LR Recommended Antennas – AP-4900MR-LR Safety and Regulatory Compliance Guide ▪ Available from C:\Program.Files\ORiNOCO\AP4900MR-LR\HTML: – AP-4900MR-LR Online Help (double-click on index.htm to launch) ▪ Available from Xtras C:\Program.Files\ORiNOCO\AP4900MR-LR\ Xtras: – TFTP Server – Acrobat Reader... -
Page 20: Unit.initialization
Select.Adapter button on the Scan List screen. ScanTool scans the subnet and displays all detected Access Points. The ScanTool’s Scan List screen appears, as shown in the following example. Page 20 Copyright © 2006 Proxim Wireless... - Page 21 If the unit still does not appear in the list, see the Troubleshooting chapter in the AP-4900MR-LR User Guide for suggestions. Note that after rebooting an Access Point, it may take up to five minutes for the unit to appear in the Scan List.
-
Page 22: Logging In
Once the AP has a valid IP Address and an Ethernet connection, you may use your web browser to monitor and configure the AP. (To configure and monitor using the command line interface, see the AP-4900MR-LR User Guide) Open a Web browser on a network computer. -
Page 23: Using The Setup Wizard
To configure the AP using the Setup Wizard, see Using.the.Setup. Wizard,.below. To configure the AP without using the Setup Wizard, click Exit. Upon clicking Exit, the System Status screen will appear. See the “Advanced Configuration” chapter in the AP-4900MR-LR User Guide for configuration instructions. using the setup wizard The Setup Wizard provides step-by-step instructions for how to configure the Access Point’s basic operating parameters, such as Network Name, IP... -
Page 24: Installing The Software
Follow the prompts provided by the Setup Wizard to perform an initial configuration of the AP. See the AP-4900MR-LR User Guide for more detailed Setup Wizard instructions and for Advanced Configuration instructions. Installing the software Proxim periodically releases updated software for the AP-4900MR-LR on its support Web site, http://support.proxim.com. - Page 25 Click OK to continue with the operation or Cancel to abort the operation. If the operation is unsuccessful, you will receive an error message. See the AP-4900MR-LR User Guide for more information. If the operation is successful, you will receive a confirmation message.
-
Page 26: Frequencies.and.bandwidths
4955 4960 4960 4965 4970 4975 4980 4985 = Occupied bandwidth for specified center frequency. Page 26 Copyright © 2006 Proxim Wireless... -
Page 27: Technical.services.and.support
If you are having trouble utilizing your Proxim product, please review the AP- 4900MR-LR User Guide and the additional documentation provided with your product. If you require additional support, please refer to the “Technical Services and Support” chapter in the AP-4900MR-LR User Guide for details about the information you will need to gather before using the Support Options listed below. - Page 28 2115 O’Nel Drive San Jose, CA (408) 731-2700...
