Proxim MeshMax 3500W Specifications

MeshMax ™ Series
Product 3500WM, 3500W, 5054WM, 5054W
Description Industry's fi rst convergence of WiMAX,
Wi-Fi Mesh and Wi-Fi
Applications • Network operator can deliver
bundle of IPTV, VoIP and Internet
access to subscribers
• Secure and reliable backhaul of
Wi-Fi Mesh traffi c
• Security and surveillance
Environments • Municipal, rural and service provider
broadband networks
• Enterprise campus networks
Key Features • Tri-radio design provides WiMAX
backhaul, Wi-Fi Mesh link and Wi-Fi
access in one device
• Simplifi es network architecture,
deployment and management
• Signifi cantly reduces TCO with
lowest deployment cost per
square mile
SPECIFICATIONS
Frequency Band • 3.5 GHz or 5.15-5.85 GHz (WiMAX link)
• 5.15-5.85 GHz (Mesh link)
• 2.4 GHz or 5.15-5.85 GHz (Wi-Fi access)
RF Protocol • 802.16-2004 or WORP (WiMAX)
• 802.11a (Wi-Fi and Mesh)
• 802.11a, 802.11b/g (Wi-Fi)
Data Rate 25.4 Mbps (3.5 GHz)
54 Mbps (5.15-5.85 GHz and 2.4GHz)
QoS • 802.16d QoS (WiMAX)
• Draft 802.11e; 802.1p; 802.1q
(Wi-Fi Mesh)
Security • AES (WiMAX)
• 802.11i, AES, TKIP (Wi-Fi Mesh)
Form Factors ODU tri-radio device, 3 x
Type-N connectors
For detailed technical specifi cations, please go to http://www.proxim.com/products/meshmax
©2007 Proxim Wireless Corporation. All rights reserved. Proxim, the Proxim logo and ORiNOCO are registered trademarks and MeshMAX and Tsunami are trademarks of Proxim Wireless Corporation. All other
trademarks mentioned herein are property of their respective owners. Specifi cations are subject to change without notice. Availability subject to local regulations. *Intent of specifi cations is to provide a guideline
of the product's performance, not to provide absolute specifi cations. Performance results may vary due to environment and implementation.
ATAG_407_MESH_US
ORiNOCO ® Wi-Fi ® Mesh Series
AP-4000MR(-LR) AP-4000M/AP-4000
High-capacity, multiple-use outdoor Dual-radio enterprise-class indoor AP
Wi-Fi mesh system with QoS, simultaneous a/b/g support
and enhanced security
• Metro-area Wi-Fi coverage with • LAN extension for nomadic access
fully redundant wireless backbone to corporate network, Internet and
• Mobile wireless networking at edge e-mail
of network • Hotspot
• Voice, video and data transmission • Guest access to Internet
with optimal economics • Voice, video and data
• Municipal and rural broadband • Enterprises
networks • Hotspots: retail, hotel, airport
• Service provider broadband • K-12 and higher education
networks
• Enterprise campus networks
• Dual-radio outdoor access point • Dual-radio design offers operational
• 802.11b/g Wi-Fi access fl exibility and high capacity
• ORiNOCO Mesh Creation Protocol • User-selectable 802.11a, b or g
(OMCP) for backhaul at 5 GHz operation
• Fast handoffs for mobility • IEEE 802.11i and AES encryption
• Secure management • QoS for latency-sensitive voice, data
• Enterprise class security and video applications
• Extended range (-LR Models)
• QoS
• 2.4 GHz or 5.15-5.85 GHz for access • 2.4 GHz for access
• 5.47-5.725 GHz for backhaul • 5.15-5.85 GHz for backhaul
(AP-4000MR)
• 5.745-5.85 GHz for backhaul
(AP-4000MR-LR)
• 802.11b/g • 802.11b/g
• 802.11a • 802.11a
54 Mbps 54 Mbps
Draft 802.11e; 802.1p; 802.1q Draft 802.11e; 802.1p, 802.1q
• 802.11i • 802.11i
• AES Encryption, TKIP • AES Encryption, TKIP
ODU dual-radio, 2 x Type-N connectors IDU with external antenna connectors
Proxim Wireless At-a-Glance
®
Wi-Fi Mesh Product Portfolio
ORiNOCO ® Public Safety Wi-Fi
AP-4900MR-LR
High-capacity, outdoor Wi-Fi Mesh
system for Public Safety applications
• Metro-area and mobile Wi-Fi
coverage using 4.9 GHz U.S.
public safety
• Voice, video and data transmission
for mobile public safety vehicles
• Municipal and rural broadband
networks
• Public safety networks including
fi re, police and emergency fi rst
responders
• Security and surveillance
• Dual-radio outdoor access point
• 802.11b/g Wi-Fi access
• ORiNOCO Mesh Creation Protocol
(OMCP) for backhaul at 4.9 GHz
• Fast handoffs for mobility
• Secure management
• Enterprise class security
• Extended range
• QoS
• 2.4 GHz for access
• 4.9 GHz for backhaul
• 802.11b/g
• 802.11a
54 Mbps
Draft 802.11e; 802.1p; 802.1q
• 802.11i
• AES Encryption, TKIP
ODU dual-radio, 2 x Type-N connectors
® Mesh Series
AP-4900M
Dual-radio indoor AP with QoS,
simultaneous a/b/g support and
enhanced security for public safety
• Metro-area and mobile Wi-Fi
coverage using 4.9 GHz U.S.
public safety
• Voice, video and data transmission
for mobile public safety vehicles
• Municipal and rural broadband
networks
• Public safety networks including
fi re, police and emergency fi rst
responders
• Security and surveillance
• Dual-radio indoor base station
• 802.11b/g Wi-Fi access
• ORiNOCO Mesh Creation Protocol
(OMCP) for backhaul at 4.9 GHz
• Fast handoffs for mobility
• Secure management
• Enterprise class security
• QoS
• 2.4 GHz for access
• 4.9 GHz for backhaul
• 802.11b/g
• 802.11a
54 Mbps
Draft 802.11e; 802.1p; 802.1q
• 802.11i
• AES Encryption, TKIP
IDU with external antenna connectors
