!0
*
Cable type
Nil
Without cable
S
Standard cable
R
Robotic cable (Flexible cable)
* The motor and encoder cables are included.
(The lock cable is also included when the
motor with lock option is selected.)
* Standard cable entry direction is
· Top/Parallel: (A) Axis side
· In-line: (B) Counter axis side
!3
*
I/O cable length [m]
Nil
Without cable
H
Without cable (Connector only)
1
1.5
* When "Without driver" is selected for driver
type, only "Nil: Without cable" can be selected.
Refer to the WEB catalog if I/O cable is
required.
Compatible Drivers
Pulse input type/
Positioning type
Driver type
Series
Number of point tables
Pulse input
Applicable network
Control encoder
Communication function USB communication
Power supply voltage (V)
* Copper and zinc materials are used for the motors, cables, controllers/drivers.
Electric Actuator/Rod Type
!1
Cable length
Nil
2
5
A
* The length of the encoder, motor and lock
cables are the same.
* Specifications and dimensions for the 25A-series are the same as standard products.
Pulse input type
LECSA
Up to 7

—
Incremental
17-bit encoder 18-bit encoder
USB communication, RS422 communication USB communication, RS422 communication
Motor mounting position:
Top/Parallel
*
[m]
Without cable
2
5
10
CC-Link direct
input type
LECSB LECSC
— Up to 255 (2 stations occupied)

— CC-Link
Absolute Absolute
18-bit encoder
100 to 120 VAC (50/60 Hz)
200 to 230 VAC (50/60 Hz)
25A-LEY
Series
Size
Motor mounting position:
In-line
!2
*
Driver type
Compatible drivers Power supply voltage (V)
Nil
Without driver
A1
LECSA1-S 100 to 120
A2
LECSA2-S 200 to 230
B1
LECSB1-S 100 to 120
B2
LECSB2-S 200 to 230
C1
LECSC1-S 100 to 120
C2
LECSC2-S 200 to 230
S1
LECSS1-S 100 to 120
S2
LECSS2-S 200 to 230
* When the driver type is selected, the cable is
included. Select cable type and cable length.
Example)
S2S2: Standard cable (2 m) + Driver (LECSS2)
S2 : Standard cable (2 m)
Nil : Without cable and driver
SSCNET# type
LECSS
—
— —
SSCNET3
Absolute
18-bit encoder
USB communication
25, 32
—
160
A
