Thank you for choosing our product. GENIUS is sure that it will give you all the performances you are looking for. All our products
are the result of a long experience in the field of the automated systems, reinforced by the fact of being part of the world
leading group of this sector.
The Sprint 11 SW control unit was designed and built to control operators for sliding gates powered voltage of 230Vac or 115Vac
through the automatic detection of mains voltage and frequency, therefore a single board independently of the input voltage.
Thanks to this innovative switching power circuit the board does not suffer from any variations of the mains voltage, thus keeping
the output value constant both on motor and accessories.
The very simple programming of the main functions reduces installation time, whereas a series of built-in LEDs ensures immediate
troubleshooting as to the condition of safety devices, travel limit devices, STOP input, radio inputs of OPEN A and OPEN B and
the presence of the mains power supply.
Thanks to the ongoing motor control (virtual encoder) and to the possibility to adjust the motor power, the Sprint 11 SW control
unit, if correctly installed and adjusted, reduces the number of accessories necessary to realise an installation conforming to
the current safety standards.
Power supply voltage and frequency
Absorbed power
Maximun power at initial thrust
Maximum load of accessories
Operating ambient temperature
Protective fuses
Function logics
Opening / Closing max. time
Pause time
Motor power
Terminal board inputs
Rapid connector
Terminal board outputs
Board dimensions
2.1. PROTECTIVE FUSES
4 fuses are located on the control unit to protect the power supply and the various accessories connected to the board:
Fuse
F1=T3.15A 250V 5x20
RW1= 700mA Self-resetting
Differently from the fuses that can be replaced – where you find the broken element – the high safety level of the self-resetting
fuses makes it possible, by opening a contact, to protect the board against any overloads or short-circuits. The operation of the
self-resetting fuses can only be found out following to a missed operation of the accessories protected by the fuse. To check
the intervention of the fuse, operate as follows:
1. Cut power to the board.
Check the connection of the non-operating accessories, paying attention to any short-circuit.
2.
3. Check the maximum allowed load according to the instructions.
4. Wait for at least 5 minutes, then supply the board with power.
To ensure people's safety, all warnings and instructions in this booklet must be carefully observed. Incorrect installation
or incorrect use of the product could cause serious harm to people.
Keep the instructions for future reference.
• Make sure that an adequate differential switch is installed upstream of the system as specified by current safety standards.
• On the mains power supply, install a thermal breaker with omnipolar switching.
• Make sure that an adequate earthing system is available.
• To lay cables, use adequate rigid and/or flexible tubes.
• Always separate the 230/115 Vac power cables from low voltage connection cables, using separate sheaths to avoid
possible interference.
1. GENERAL CHARACTERISTICS
2. TECHNICAL SPECIFICATIONS
Protection
Mains power supply
Flashing lamp output
3. PREPARATIONS
SPRINT 11 SW
230Vac 50Hz / 115Vac 60Hz
120 W
500 mA
-20°C — +55°C
4 (3 of which self-resetting)
Automatic / Step-by-step automatic / Semiautomatic /
Step-by-step semiautomatic
120 seconds
through self-learning during programming phase (max. 4
minutes)
trimmer-adjustable
Mains power supply / Travel limit device at opening / Travel
limit device at closing / STOP / Safety devices / OPEN A /
OPEN B / Batteries
Battery charger / Radio receiver
Motor power supply / Accessories power supply /
Flashing lamp/
144 x 116 mm
Fuse
RW2= 700mA Self-resetting Self-resetting
RW3= 500mA Self-resetting Self-resetting
Pagina 1
Guide for the installer
3 W
Protection
Battery-charger circuit
Power supply for accessories
