The control unit has an integrated 2-channel decoding system. This system makes it possible to memory store, via the receiver
module, both the OPEN A command and the OPEN B command.
The decoding system makes it possible to memory store both the radio controls with a frequency of 868 MHz and the radio
controls with a frequency of 433 MHZ.
Only one radio code can be used at a time. To change over from one code to the other, delete the existing radio code
(see paragraph 11.3), replace the receiver module and repeat the programming phases.
Fitting and, if necessary, removing the receiver module must be done only after cutting power to the board.
The receiver module can only be inserted in one position. Orient the module correctly without forcing.
11.1. Memory storage of 868 MHz radio controls
You can memory store up to a maximum of 250 codes, subdivided between the two channels, OPEN A and OPEN
B.
1. On the radio control, simultaneously press and hold down push-buttons P1 and P2 (see radio control instructions).
2. After about one second, the LED on the radio control begins to flash.
3. Release both push-buttons.
4. Press and hold down push-button OPA or OPB on the board to respectfully memory store the OPEN A or OPEN B channel.
The relevant LED begins to flash.
5. Simultaneously press the push-button on the radio control with which you wish to associate the selected command.
6. Check if the LED relating to the command being memory stored (OPA for the OPEN A channel or OPB for the OPEN B
channel) lights up on steady beam for about two seconds to confirm correct memory storage.
To finish programming, press twice in close succession, the push-button of the memory stored radio control.
7.
The automated system will perform an opening manoeuvre – make sure that there are no obstacles inside the operating
range.
8. To memory store the other channel, repeat all the procedure from point 1.
To add other radio controls, transfer the code of the memory-stored push-button of the radio control to the relevant
push-button of the radio controls to be added, observing the following procedure:
• On the memory stored radio control, simultaneously press and hold down push-buttons P1 and P2 (see radio control
instructions).
• The radio control LED begins to flash.
• Release both push-buttons.
• Put the two radio controls frontally into contact.
• On the memory stored radio control, press and hold down the push-button relating to the channel you wish to transfer
- the radio control LED lights up on steady beam.
• On the radio control to be memory stored, press the required push-button and release it after the radio control has flashed
twice.
• To finish programming, press twice in close succession, the push-button of the memory stored radio control.
The automated system will perform an opening manoeuvre – make sure that there are no obstacles inside the operating
range.
11.2. Memory storage of 433 MHz radio controls
You can memory store up to a maximum of 250 codes, subdivided between the two channels, OPEN A and OPEN
B.
1. On the control unit, press the push-button of the channel you wish to memory store, OPA for the OPEN A channel or OPB
for the OPEN B channel.
2. The relevant LED on the control unit begins to flash – release the push-button.
3. On the radio control, press the push-button with which you wish to associate the selected channel.
4. The LED on the control unit lights up on steady beam for about one second, signalling that the radio control was stored
in the memory and then starts to flash again.
5. During this stage further radio controls can be stored in the memory.
6. After about 10 seconds, the control unit automatically exits the learning stage.
7. To add other radio controls or memory store the second channel, repeat the operations from point 1.
11.2.1. r
emOte memOry StOrAge OF tHe
Other radio controls can be remotely stored only with the 433 radio controls, i.e. without using the push-buttons of the control
unit, but using a previously memory stored radio control.
1. Get a radio control already memory stored on one of the 2 channels.
2. Step near the automated system.
3. Simultaneously press and hold down push-buttons P1 and P2 (see radio control instructions) for about 5 seconds.
4. Within 5 seconds, press on the memory stored radio control, the push-button you wish to transfer to the new radio control.
In this way the learning stage on the selected channel is activated on the control unit.
5. Within 5 seconds press, on the new radio control, the push-button you wish to associate with the selected channel.
6. After the new radio control has been stored in the memory, the control unit keeps the learning mode active on the
selected channel for about 5 seconds.
During these 5 seconds, other radio controls can be memory stored on the control unit, as ever associated with the
7.

11. MEMORY STORING THE RADIO CODE

433 mH
z rAdiO cOntrOlS
