Page 8 SPRINT 05 SW
Guide for the installer
We thank you for having chosen one of our products. GENIUS is certain that from it you will obtain all the performance you require. All
our products are the result of years of experience in the field of automated systems, with the added advantage of being part of one of the
sector's world leading groups.
The SPRINT 05 SW control unit has been designed to control sliding operators with a maximum power of 600W.
The SW models are able to automatically recognise the input voltage with values that range from 95 V~ to 260 V~ (50 / 60 Hz). This
makes it possible to obtain constant output of both the motor and accessories, and therefore extremely smooth operation of the gear train
regardless of any possible sudden changes in voltage that may occur throughout the day.
Thanks to the active and passive safety controls, if correctly installed, it guarantees installation compliant with the safety regulations in
force. The fact that an encoder can also be managed makes it possible to further increase the level of safety.
The extreme simplicity in programming the main functions greatly reduces installation time.
Thanks to the 5 built-in LEDs, it is able to provide the state of the safety devices and limit switches at any given moment.
Power voltage
Absorbed power
Max. load of motor
Max. load of accessories
Operating ambient temperature
Safety fuses
Operating logics
Open /Close time
Pause time
Motor power
Terminal board inputs
Terminal board outputs
Rapid connector
Programmable functions
Dimensions
CN1 Encoder connector
CN2 Low-voltage terminal board
CN3 High- voltage terminal board
CN4 Receiver connector
CN5 Limit switch connector
CN6 Capacitor connector
TR1 Motor power adjustment trimmer
For safety reasons, it is important for people to carefully follow all the warnings and instructions contained in this booklet.
Incorrect installation or incorrect use of the product can cause serious harm to people.
• Ensure that upstream from the system there is a suitable differential switch, as provided for in current safety regulations, and fit an
omnipolar magnetothermic switch on the power grid.
• Check for the presence of an adequate earthing system.
• For cable installation use adequate rigid and/or flexible tubes.
• Always separate the power cables from the low-voltage control cables. To avoid any interference, we recommend using separate sheathing.
5.1. CONNECTOR CN1
This connector is for use with an encoder. For encoder operation, refer to paragraph 8.
5.2. TERMINAL BOARD CN2 (Fig. 2)

1. GENERAL CHARACTERISTICS

2. TECHNICAL SPECIFICATIONS

Open A, Open B, Stop, Limit switch when opening, Limit switch when closing, Photocells,
24 Vdc accessories power, Flashing lamp, Motor, Earthing
Connector for 5-pin receivers, Encoder, Limit switch, Capacitor
Operating logic, Pause time, Clutch sensitivity, Operation with encoder,
3. BOARD LAY-OUT (Fig.1)
DP1
F1
ALIM
FSW
STOP
FCA
FCC
4. PREPARATIONS

5. CONNECTIONS AND OPERATION

230V~ 50Hz / 115V~ 60Hz
15 W
600 W
500 mA
-20°C +55°C
1
Automatic, Manual
120 sec.
Four pre-set levels
Adjustable using a trimmer
Power
Safety logic, Condo function
145 x 105
Parameter setting dip-switch
Power/Motor fuses 3.15A T (5x20)
Network power present LED
FSW input state LED
STOP input state LED
FCA input state LED
FCC input state LED
